Plastic Barbed Fittings, Parker Par-Barbs - 30GH-12

Name: Plastic Barbed Fittings, Parker Par-Barbs - 30GH-12
SKU: 30GH-12

Parker's Par-Barb fttings are specially engineered with a four-barb design that generates maximum gripping and sealing power when combined with a hose clamp.

Availability:

Backordered

SKU 30GH-12

$2.03

Products specifications

Attribute name	Attribute value
UOM	EA	Color	White
Connection 2 Hose I.D. (inch)	n/a	Connection 1 Size	3/4"
Body Material	Nylon,White	Configuration	Pipe to Pipe
Connection 3 Size	N/A	Connection 3 Type	N/A
Connection 1 Thread Size	3/4"	Connection 1 Hose I.D. (inch)	n/a
Shape	Washer	Product Style	Garden Hose Thread
Connection 1 Type	Female Garden Hose	Connection 2 Size	N/A
Connection 2 Type	N/A	Brand	PARKER
Division	Fluid System Connectors Division	Color	White
Minimum Operating Temperature	-40 °F	Division	Fluid System Connectors Division
Technology	Fluid & Gas Handling	Connection 2 Size	n/a
Configuration	Pipe to Pipe	Body Material	Polypropylene
Maximum Operating Temperature	200 °F	Compatible Tube	Vinyl
Connection 1 Size	3/4	Connection 3 Size	N/A
Connection 3 Type	N/A	Vacuum Pressure Rating	-29
Maximum Operating Pressure	8.5 bar	Dimensional Weight	0.5755 lb
Specifications Met	FDA, NSF-51	Media	Water, Air, Other Compatible Fluids
Shape	Washer	Application	Chemical Dispensing, Pneumatic Systems, Food Processing, Beverage Dispensing
Tube Material	Vinyl, Polyurethane, Rubber Hose	Connection 1 Type	Garden Hose
Connection 2 Type	N/A
