31HB-4PP - Plastic Barbed Fittings, Parker Par-Barbs

Parker's Par-Barb fttings are specially engineered with a four-barb design that generates maximum gripping and sealing power when combined with a hose clamp.

Availability:	Backordered Estimated Lead Time: 25 days
Partner Available:	Backordered

SKU 31HB-4PP

Products specifications

Attribute name	Attribute value
UOM	EA	Color	Black
Connection 1 Size	1/4"	Connection 1 Type	Female Pipe
Connection 2 Hose I.D. (inch)	n/a	Body Material	Polypropylene, Black
Configuration	Pipe to Pipe	Connection 3 Size	N/A
Connection 3 Type	N/A	Connection 1 Thread Size	1/4"
Connection 1 Hose I.D. (inch)	n/a	Connection 2 Size	N/A
Connection 2 Type	N/A	Shape	Swivel Nut
Product Style	Female Pipe	Connection 1 Size	1/4
Connection 2 Size	n/a	Color	Black
Configuration	Pipe to Pipe	Body Material	Polypropylene
Maximum Operating Temperature	220 °F	Compatible Tube	Vinyl
Connection 3 Size	N/A	Connection 3 Type	N/A
Vacuum Pressure Rating	-29	Maximum Operating Pressure	8.5 bar
Minimum Operating Temperature	10 °F	Specifications Met	FDA, NSF-51
Media	Water, Air, Other Compatible Fluids	Tube Material	Vinyl, Polyurethane, Rubber Hose
Connection 2 Type	N/A	Shape	Swivel Nut
Connection 1 Type	Female NPT
