Picture of PRDM Series - Pressure Reducing - NFPA D05 (CETOP 5, NG 10) - PRDM3AA01SNS

*PRODUCT IMAGE IS REPRESENTATIVE PROVIDED BY THE MANUFACTURER. DO NOT MAKE BUYING DECISIONS SOLEY BASED ON THE IMAGE. PLEASE VERIFY SPECIFICATIONS MEET YOUR REQUIREMENTS.

PRDM Series - Pressure Reducing - NFPA D05 (CETOP 5, NG 10) - PRDM3AA01SNS

PRDM Series - Pressure Reducing Parker Manapak Subplate Sandwich Module
Availability:
Backordered
SKU PRDM3AA01SNS
$1,525.44
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options
Products specifications
Attribute nameAttribute value
UOMEAControlled PortsA Port
Gauge Port Size4 SAEAdjustment TypeScrew
Max Flow (at 3000 PSI)21 GPM (81 LPM)SealsBuna-N (Nitrile)
Pressure Range15 to 200 PSI (1 to 14 Bar)Pkg Qty1
UOMEASeriesPRDM
Parker GroupHydraulicAdjustment TypeScrew
Controlled PortsA PortSubplate PatternNFPA D05 (CETOP 5, NG 10)
Max Flow (at 3000 PSI)21 GPM (81 LPM)Port TypeSAE
Pressure Range15 to 200 PSI (1 to 14 Bar)SealsBuna-N (Nitrile)
Parker DivisionHydraulic ValveMax Pressure4500 PSI (315 Bar)
Port Size4 SAE
