Prep-Air II FRL Filters (Particulate/Coalescing)

Prep-Air II heavy duty particulate filters (05F, 06F, 07F) delivers high moisture and solid particle contaminant removal down to 5 micron. This type of filter is generally used in industrial applications where liquid water, oil, and harmful dirt particles must be removed from the compressed air system. For specific flow and space restricted applications, this product can provide a solution that does not sacrifice performance. The Prep-Air II particulate filters can also be mounted using a modular connector to other Prep-Air II air preparation products. The various options available (such as auto drain, manual drain, and an assortment of bowl options) make this series easy to design to your application.

Prep-Air II coalescing filters (11F, 12F, 15F) are designed to remove oil, water and liquid aerosols and submicron particulate matter from your pneumatic system. These coalescing filters are specifically designed for the removal of solid particles, water and oil aerosols down to 0.01 micron. Prep-Air II coalescing filters come standard with a polycarbonate bowl, wrapped with a metal bowl guard, providing 360 degrees of visibility to content inside the bowl. The various options available (such as auto drain, twist drain, DPI gauge and assortment of bowl options) make this series easy to configure for your application. The Prep-Air II coalescing filters can also be mounted using a modular connector to other Prep-Air II air preparation products.

Markets:

·       Air and Gas

·       Appliances

·       Entertainment Automation

·       Factory Automation

·       Food and Beverage

·       Machine Tools

·       Misc. Industrial

·       Misc. Manufacturing

·       Misc. Processing

·       Molding

·       Packaging Machinery

·       Printing and Marking Equipment

·       Vehicle Assembly Facilities

·       Wearing Apparel

Features/Benefits:

·       Interchangeable twist and automatic float drains

·       Metal bowl with sight glass

·       Easily configured and designed for your application

Particulate Filters

   • Excellent water removal efficiency

   • Unique deflector plate and shroud creates a swirling of the air stream ensuring maximum water and dirt separation

   • Large filter element surface guarantees low pressure drop and increased element life

   • Optional automatic float drain available

   • High rate of particulate removal

Coalescing Filters

   • Removes liquids and submicron particles

   • Differential pressure indicator standard

   • Liquids gravitate to the bottom of the element and will not re-enter the airstream

   •  Oil free air for critical applications, such as air gauging and pneumatic instrumental and controls

Applications:

·       To be used in combination with valves and cylinders

·       To protect tools and cylinder against corrosion

·       To reduce friction

·       At the transfer point from workshop to machine

·       In combination with tools for assembly and on the shop floor

·       For all type of machines and tools pneumatic driven
