6621-2000025 - Silicone Greek Corrugated High Temperature Wire Reinforced Coolant Hose, Series 6621

Silicone Greek Corrugated High Temperature Wire Reinforced Coolant Hose is for use in heater and radiator systems in heavy duty/high capacity vehicles and industrial equipment to 75 psi and 392°F, Series 6621

Availability:	Backordered Estimated Lead Time: 211 days
Partner Available:	14 in stock

SKU 6621-2000025

$90.63/foot

Bypass upcharge for backordered quantity. Check this box if you prefer to backorder out of stock quantities from Hyspeco for this item, then click Add To Cart.

Products specifications

Attribute name	Attribute value
UOM	FT	Standard Pack Qty (ft)	25
Hose I.D. (inch)	2	Minimum Burst Pressure (psi)	225
Media	Water	Package Type	Coil
Maximum Operating Pressure	5 bar	Cover Color	Red
Inside Diameter	51 mm	Outside Diameter	64 mm
Weight	0.88 lb	Specifications Met	SAE J20R1, Class A
Vacuum Pressure Rating	17.7 Inch-Hg	Maximum Operating Temperature	392 °F
Minimum Operating Temperature	-76 °F	Cover Material	Silicone
Cover Structure	Greek-Corrugated	Minimum Bend Radius	150.1 mm
Hose Inner Tube Material	Silicone	Hose Reinforcement Material	Multiple Plies of High Temperature Textile with Wire Helix
Design Factor	3:1	Minimum Burst Pressure	225 psi

Product resources

Literature and Reference Materials

Hose Products Division Catalog 4400 - Hose, Fittings, Accessories and Equipment (PDF)
