CPIFF-12S-15 - Soft Seat, Hydraulic In Line Check Valves - CPIFF Series

Parker's, in line check valves are one way flow control devices used primarily in hydraulic systems to eliminate potential damage caused by fluid back pressure.

Availability:	Backordered Estimated Lead Time: 19 days
Partner Available:	Backordered

SKU CPIFF-12S-15

$84.89/each

Bypass upcharge for backordered quantity. Check this box if you prefer to backorder out of stock quantities from Hyspeco for this item, then click Add To Cart.

Products specifications

Attribute name	Attribute value
UOM	EA	Seal Material	Fluorocarbon
Body Size (inch)	3/4	Cracking Pressure (psi)	15
Inlet Port Connection Type	Female SAE Straight Thread	Outlet Port Connection Type	Female SAE Straight Thread
Inlet Port Size (inch)	1 1/16 - 12 UN	Outlet Port Size (inch)	1 1/16 - 12 UN
Body Material	Steel	Maximum Operating Temperature	400 °F
Maximum Operating Pressure	5000 psi	Minimum Operating Temperature	-15 °F
Actuation Type	Mechanical	Maximum Flow Rate	n/a
Seat Type	Soft Seat
