Picture of Standard Pilot Assisted Load Control Valves - CB101AS30

*PRODUCT IMAGE IS REPRESENTATIVE PROVIDED BY THE MANUFACTURER. DO NOT MAKE BUYING DECISIONS SOLEY BASED ON THE IMAGE. PLEASE VERIFY SPECIFICATIONS MEET YOUR REQUIREMENTS.

Standard Pilot Assisted Load Control Valves - CB101AS30

Parker’s piloted load control valves are designed to operate independent of downstream pressure to prevent runaway loads under dynamic conditions using a pilot signal, handling pressures up to 420 bar (6000 psi) and flows up to 350 lpm (90 gpm).
Availability:
27 in stock
Olivette, MO27
SKU CB101AS30
$113.75
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options
Products specifications
Attribute nameAttribute value
UOMEASeal MaterialNitrile
Port Sizen/aAdjustment MechanismScrew
Mounting TypeThreaded Cartridge ValveMaximum Flow Rate12 GAL/MIN, 45 L/MIN
Holding Pressure3000 PSI, 210 BARPilot Pressure Ratio3:1
Pressure Control Range2400-5000 PSI, 166-350 BARSeal MaterialNitrile
Actuation TypePilot OperatedPort Sizen/a
Maximum Operating Temperature250 °FBody Materialn/a
Maximum Operating Pressure5000 psiDivisionHydraulic Cartridge Systems Division
For Fluid TypeMineral-based Hydraulic FluidsDivisionHydraulic Systems Division
Leak Rate5Pilot LocationExternal
Valve MaterialSteelInstallation Torque16 lb-ft
Filter Efficiency RatingSAE Class 4Maximum Kinematic Viscosity45-2000 SSU (6 to 420 cSt)
Minimum Operating Temperature-30 °FWeight0.23 kg
Pressure Control Sensitivityn/aPort Thread Sizen/a
Cavity SizeC10-3Flow Rate45 L/min
FunctionCounterbalance ValveMaximum Flow Rate45 L/min
Mounting TypeThreaded Cartridge ValvePilot Pressure Ratio3:1
Flow DirectionValve port 2Holding Pressure3000 psi
Adjustment MechanismScrew AdjustmentOperating Temperature-34° to +121° °C
Pressure Control Range2400 to 5000 psiMaximum Inlet Pressure Rating380 bar
