PD222Y - Test Port, Diagnostic Quick Couplings, ISO 15171-1 - PD Series

Parker's diagnostic quick couplers and test point nipples provide easy connections for mechanical gauges or specialized diagnostic equipment including Parker's SensoControl meters and accessories.

Availability:	Backordered Estimated Lead Time: 54 days
Partner Available:	Backordered

SKU PD222Y

$65.65/each

Bypass upcharge for backordered quantity. Check this box if you prefer to backorder out of stock quantities from Hyspeco for this item, then click Add To Cart.

Products specifications

Attribute name	Attribute value
UOM	EA	Tube Size (inch)	na
Connection Thread Size (inch)	1/8 - 27	Connection Type	Female NPTF
Coupling Half	Female Coupler	Specifications Met	SAE J1502
Hex Size	0.81 inch	Flow Rate	0.8 Gal/min
Body Material	Steel	Valve Type	Non-spill
Plating Type	Zinc with clear trivalent chromate	Maximum Operating Pressure	6000 psi
Maximum Operating Temperature	400 °F	Minimum Operating Temperature	-15 °F
Body Size	1/8 inch	Seal Material	Fluorocarbon
