YAYA-16-16C - Type "M" Fitting Adapters

These fitting adapters connect to Type "M" Swivel end fittings and seal with a 58° cone.

Availability:	Backordered Estimated Lead Time: 14 days
Partner Available:	3 in stock

SKU YAYA-16-16C

$642.29/each

Bypass upcharge for backordered quantity. Check this box if you prefer to backorder out of stock quantities from Hyspeco for this item, then click Add To Cart.

Products specifications

Attribute name	Attribute value
UOM	EA	Connection 2 Type	Male Type "M"
Connection 1 Type	Male Type "M"	Connection 2 Thread Size	1-5/16"-12 UNF
Connection 1 Thread Size	1-5/16"-12 UNF	Overall Length	54.1 mm
Connection 2 Size	1-5/16"-12 inch	Connection 1 Type	Male
Connection 1 Size	1-5/16"-12 inch	Maximum Operating Pressure	20000 psi
Hex Size	35.05 mm	Connection 2 Type	Type "M"
Materials of Construction	Stainless Steel AISI 316

Product resources

Literature and Reference Materials

Catalog 4900 - Parflex Ultra High Pressure Thermoplastic Hose, Fittings and Accessories--CAT-4900 (PDF)
