Union Elbow 255IFHD - 255IFHD-4

Name: Union Elbow 255IFHD - 255IFHD-4
SKU: 255IFHD-4

Parker 45° Inverted Flare Brass Union Elbow - Ref. SAE J512 040427

Availability:

Backordered

SKU 255IFHD-4

POR

Products specifications

Attribute name	Attribute value
UOM	EA	UOM	EA
Material	Brass	Pkg Qty	1
Outer Diameter 1	1/4 Inch	Outer Diameter 2	1/4 Inch
Thread 1	7/16-24 UN/UNF	Thread 2	7/16-24 UN/UNF
Parker Group	Fluid Connector	Inch/Metric	Inch
Material	Brass	Parker Division	Fluid Systems Connector (Brass Products)
Outer Diameter 1 Inch/mm	Inch	Configuration Type	Flare to Flare
Thread 1 Type	UN/UNF	Operating Temperature	-65°F to +250°F
Thread 2 Type	UN/UNF	Outer Diameter 2 Inch/mm	Inch
Outer Diameter 1	1/4 Inch	Outer Diameter 2	1/4 Inch
Series	45° Inverted Flare	Thread 1	7/16-24 UN/UNF
Thread 2	7/16-24 UN/UNF	Configuration Sub-Type	Union Elbow 90°
Pressure Rating	1400 PSI	SAE Compliance	J512
SAE Reference	SAE 040427	Body Shape	Extruded
