*PRODUCT IMAGE IS REPRESENTATIVE PROVIDED BY THE MANUFACTURER. DO NOT MAKE BUYING DECISIONS SOLEY BASED ON THE IMAGE. PLEASE VERIFY SPECIFICATIONS MEET YOUR REQUIREMENTS.

22/23 Series - General Purpose Solenoid Valves - 06F23C2340A3FPH80

Name: 22/23 Series - General Purpose Solenoid Valves - 06F23C2340A3FPH80
SKU: 06F23C2340A3FPH80

This series is general superseded by G7 Series 22/23 Valves.

Availability:

Backordered

SKU 06F23C2340A3FPH80

$245.40

Products specifications

Attribute name	Attribute value
UOM	EA	Media	General Purpose
Function	Normally Closed	Coil Type	DIN 43650A / ISO 4400
Port Size	3/8	Port Type	NPT
Installation	IOM 7321	Orifice Size	5/8
Body Material	BRASS	Input Voltage	24.0
Seal Material	EPDM	Actuation Type	Direct Lift
Insulation Class	Class F	Power Consumption	11.5
Specifications Met	UL, CSA Recognized General Purpose Valve; CE - Low Voltage, EMC	Valve Configuration	2 Way
Main Flow Coefficient	3.0	Ingress Protection Rating	NEMA 4,4X
Maximum Fluid Temperature	150.0	Preventive Maintenance Kit	06F23C2340A3FR
Maximum Ambient Temperature	77.0	Maximum Pressure Differential	40 (N/A Light Oil)
Minimum Pressure Differential	0.0	Media	General Purpose
Function	Normally Closed	Coil Type	DIN 43650A / ISO 4400
Port Size	3/8 inch	Port Type	NPT
Installation	IOM 7321	Orifice Size	5/8 inch
Body Material	Brass	Input Voltage	24.0 VDC
Seal Material	EPDM	Actuation Type	Direct Lift
Insulation Class	Class F	Power Consumption	11.5 W
Specifications Met	UL, CSA Recognized General Purpose Valve; CE - Low Voltage, EMC	Division	Fluid Control Division
Valve Configuration	2 Way	Main Flow Coefficient	3.0 Cv
Ingress Protection Rating	NEMA 4,4X	Maximum Fluid Temperature	150.0 °F
Preventive Maintenance Kit	06F23C2340A3FR	Maximum Ambient Temperature	77.0 °F
Maximum Pressure Differential	40 (N/A Light Oil) psi	Minimum Pressure Differential	0.0 psi

Product resources

Literature and Reference Materials

Tube Seal (PDF)
