22/23 Series - General Purpose Solenoid Valves
*PRODUCT IMAGE IS REPRESENTATIVE PROVIDED BY THE MANUFACTURER. DO NOT MAKE BUYING DECISIONS SOLEY BASED ON THE IMAGE. PLEASE VERIFY SPECIFICATIONS MEET YOUR REQUIREMENTS.
Parker Gold Ring legacy product has a rich history in industrial and commerical applications.
Read More...| Action | SKU | Availability | Partner Available | Price | UOM | Media | Function | Coil Type | Port Size | Port Type | Installation | Orifice Size | Body Material | Input Voltage | Seal Material | Actuation Type | Insulation Class | Power Consumption | Specifications Met | Valve Configuration | Main Flow Coefficient | Ingress Protection Rating | Maximum Fluid Temperature | Preventive Maintenance Kit | Maximum Ambient Temperature | Maximum Pressure Differential | Minimum Pressure Differential | Media | Function | Coil Type | Port Size | Port Type | Installation | Orifice Size | Body Material | Input Voltage | Seal Material | Actuation Type | Insulation Class | Power Consumption | Specifications Met | Valve Configuration | Main Flow Coefficient | Ingress Protection Rating | Maximum Fluid Temperature | Preventive Maintenance Kit | Maximum Ambient Temperature | Maximum Pressure Differential | Minimum Pressure Differential |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 12F23C2148ACF | Backordered | 1 Limited Stock | $243.06/each | EA | General Purpose | Normally Closed | Requires Coil from Chart 4 | 3/4 | NPT | IOM 7321 | 3/4 | BRASS | Pressure Vessel Only | NBR | Direct Lift | N/A | 11.0 | N/A | 2 Way | 5.0 | N/A | 180.0 | 12F23C2148ACFR | 130.0 | 150.0 | 0.0 | General Purpose | Normally Closed | Requires Coil from Chart 4 | 3/4 inch | NPT | IOM 7321 | 3/4 inch | Brass | Pressure Vessel Only | NBR | Direct Lift | N/A | 11.0 W | N/A | 2 Way | 5.0 Cv | N/A | 180.0 °F | 12F23C2148ACFR | 130.0 °F | 150.0 psi | 0.0 psi | |
| 12F23C2148ACF4C01 | Backordered | 8 in stock | $315.78/each | EA | General Purpose | Normally Closed | 1/2" NPT Conduit w/ Leads (Incl. Ground Lead) | 3/4 | NPT | IOM 7321 | 3/4 | BRASS | 24/60 | NBR | Direct Lift | Class F | 11.0 | UL, CSA Listed Safety Shutoff Valve; CE - Low Voltage, EMC | 2 Way | 5.0 | NEMA 4,4X | 180.0 | 12F23C2148ACFR | 130.0 | 150.0 | 0.0 | General Purpose | Normally Closed | 1/2" NPT Conduit w/ Leads (Incl. Ground Lead) | 3/4 inch | NPT | IOM 7321 | 3/4 inch | Brass | 24/60 VAC | NBR | Direct Lift | Class F | 11.0 W | UL, CSA Listed Safety Shutoff Valve; CE - Low Voltage, EMC | 2 Way | 5.0 Cv | NEMA 4,4X | 180.0 °F | 12F23C2148ACFR | 130.0 °F | 150.0 psi | 0.0 psi | |
| 12F23C2148ACF4C05 | Backordered | Backordered | $315.80/each | EA | General Purpose | Normally Closed | 1/2" NPT Conduit w/ Leads (Incl. Ground Lead) | 3/4 | NPT | IOM 7321 | 3/4 | BRASS | 120/60, 110/50 | NBR | Direct Lift | Class F | 11.0 | UL, CSA Listed Safety Shutoff Valve; CE - Low Voltage, EMC | 2 Way | 5.0 | NEMA 4,4X | 180.0 | 12F23C2148ACFR | 130.0 | 150.0 | 0.0 | General Purpose | Normally Closed | 1/2" NPT Conduit w/ Leads (Incl. Ground Lead) | 3/4 inch | NPT | IOM 7321 | 3/4 inch | Brass | 120/60, 110/50 VAC | NBR | Direct Lift | Class F | 11.0 W | UL, CSA Listed Safety Shutoff Valve; CE - Low Voltage, EMC | 2 Way | 5.0 Cv | NEMA 4,4X | 180.0 °F | 12F23C2148ACFR | 130.0 °F | 150.0 psi | 0.0 psi | |
| 12F23C2348ACF4C05 | Backordered | Backordered | $359.40/each | EA | General Purpose | Normally Closed | 1/2" NPT Conduit w/ Leads (Incl. Ground Lead) | 3/4 | NPT | IOM 7321 | 3/4 | BRASS | 120/60, 110/50 | EPDM | Direct Lift | Class F | 11.0 | UL, CSA Listed General Purpose Valve; CE - Low Voltage, EMC | 2 Way | 5.0 | NEMA 4,4X | 180.0 | 12F23C2348ACFR | 130.0 | 150.0 | 0.0 | General Purpose | Normally Closed | 1/2" NPT Conduit w/ Leads (Incl. Ground Lead) | 3/4 inch | NPT | IOM 7321 | 3/4 inch | Brass | 120/60, 110/50 VAC | EPDM | Direct Lift | Class F | 11.0 W | UL, CSA Listed General Purpose Valve; CE - Low Voltage, EMC | 2 Way | 5.0 Cv | NEMA 4,4X | 180.0 °F | 12F23C2348ACFR | 130.0 °F | 150.0 psi | 0.0 psi | |
| 12F23C6448ACFPH01 | Backordered | Backordered | $1,105.44/each | EA | General Purpose | Normally Closed | DIN 43650A / ISO 4400 | 3/4 | NPT | IOM 7321 | 3/4 | 316 Stainless Steel | 24/60 | PTFE | Direct Lift | Class F | 11.0 | UL, CSA Recognized General Purpose Valve; CE - Low Voltage, EMC | 2 Way | 5.0 | NEMA 4,4X | 180.0 | 12F23C6448ACFR | 130.0 | 150.0 | 0.0 | General Purpose | Normally Closed | DIN 43650A / ISO 4400 | 3/4 inch | NPT | IOM 7321 | 3/4 inch | 316 Stainless Steel | 24/60 VAC | PTFE | Direct Lift | Class F | 11.0 W | UL, CSA Recognized General Purpose Valve; CE - Low Voltage, EMC | 2 Way | 5.0 Cv | NEMA 4,4X | 180.0 °F | 12F23C6448ACFR | 130.0 °F | 150.0 psi | 0.0 psi | |
| 12F23O2148ACF4C05 | Backordered | Backordered | $532.23/each | EA | General Purpose | Normally Open | 1/2" NPT Conduit w/ Leads (Incl. Ground Lead) | 3/4 | NPT | IOM 7321 | 3/4 | BRASS | 120/60, 110/50 | NBR | Direct Lift | Class F | 11.0 | UL, CSA Listed General Purpose Valve; CE - Low Voltage, EMC | 2 Way | 5.0 | NEMA 4,4X | 150.0 | 12F23O2148ACFR | 130.0 | 150.0 | 0.0 | General Purpose | Normally Open | 1/2" NPT Conduit w/ Leads (Incl. Ground Lead) | 3/4 inch | NPT | IOM 7321 | 3/4 inch | Brass | 120/60, 110/50 VAC | NBR | Direct Lift | Class F | 11.0 W | UL, CSA Listed General Purpose Valve; CE - Low Voltage, EMC | 2 Way | 5.0 Cv | NEMA 4,4X | 150.0 °F | 12F23O2148ACFR | 130.0 °F | 150.0 psi | 0.0 psi |
