797TC Series
*PRODUCT IMAGE IS REPRESENTATIVE PROVIDED BY THE MANUFACTURER. DO NOT MAKE BUYING DECISIONS SOLEY BASED ON THE IMAGE. PLEASE VERIFY SPECIFICATIONS MEET YOUR REQUIREMENTS.
Parker’s GlobalCore 797ST hose provides 6,000 psi (35 MPa) constant working pressure in all sizes. ½ bend radius of SAE spiral hose. Flex impulse tested providing a hose superior in both performance and service life. Meets ISO 18752 performance specification.
Read More...| Action | SKU | Availability | Partner Available | Price | UOM | UOM | Material | Inner Diameter | Working Pressure | Mating Fitting Series | Pkg Qty | Pkg Qty/UOM | Parker Division | Working Pressure Range | Distinct Properties | Inch/Metric | Trade Name | Working Pressure | Specification | Application | Inner Diameter Inch/mm | Parker Group | Minimum Bend Radius | Hose Pressure Range | Inner Diameter | Mating End Fitting Series | Hose Category | Series | Material | Operating Temperature | ISO 18752 Performance |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 797TC-10-BX | Backordered | Backordered | $38.60/foot | FT | FT | Rubber | 0.625 Inch | 6,000 psi (42 MPa) | 77 | 50 | 50 FT | Hose Products | > 5000 PSI (345 bar) | Tough Cover Constant Pressure 6000 PSI | Inch | GlobalCore | 6,000 psi (42 MPa) | ISO 18752 | Hydraulic | Inch | Fluid Connector | 4 1/2 Inch | High | 0.625 Inch | 77 | Hydraulic Industry Standard | 797TC | Rubber | -40°F to +257°F (-40°C to +125°C) | DC | |
| 797TC-10-RL | 350 in stock | 2823 in stock | $31.18/foot | FT | Rubber | 0.625 Inch | 6,000 psi (42 MPa) | 77 | Hose Products | > 5000 PSI (345 bar) | Tough Cover Constant Pressure 6000 PSI | Inch | GlobalCore | 6,000 psi (42 MPa) | ISO 18752 | Hydraulic | Inch | Fluid Connector | 4 1/2 Inch | High | 0.625 Inch | 77 | Hydraulic Industry Standard | 797TC | Rubber | -40°F to +257°F (-40°C to +125°C) | DC | ||||
| 797TC-12-BX | Backordered | Backordered | $54.86/foot | FT | FT | Rubber | 0.75 Inch | 6,000 psi (42 MPa) | 77 | 50 | 50 FT | Hose Products | > 5000 PSI (345 bar) | Tough Cover Constant Pressure 6000 PSI | Inch | GlobalCore | 6,000 psi (42 MPa) | ISO 18752 | Hydraulic | Inch | Fluid Connector | 5 1/4 Inch | High | 0.75 Inch | 77 | Hydraulic Industry Standard | 797TC | Rubber | -40°F to +257°F (-40°C to +125°C) | DC | |
| 797TC-12-RL | 1399 in stock | 11101 in stock | $44.32/foot | FT | Rubber | 0.75 Inch | 6,000 psi (42 MPa) | 77 | Hose Products | > 5000 PSI (345 bar) | Tough Cover Constant Pressure 6000 PSI | Inch | GlobalCore | 6,000 psi (42 MPa) | ISO 18752 | Hydraulic | Inch | Fluid Connector | 5 1/4 Inch | High | 0.75 Inch | 77 | Hydraulic Industry Standard | 797TC | Rubber | -40°F to +257°F (-40°C to +125°C) | DC | ||||
| 797TC-16-BX | Backordered | Backordered | $67.45/foot | FT | FT | Rubber | 1 Inch | 6,000 psi (42 MPa) | 77 | 50 | 50 FT | Hose Products | > 5000 PSI (345 bar) | Tough Cover Constant Pressure 6000 PSI | Inch | GlobalCore | 6,000 psi (42 MPa) | ISO 18752 | Hydraulic | Inch | Fluid Connector | 6 1/2 Inch | High | 1 Inch | 77 | Hydraulic Industry Standard | 797TC | Rubber | -40°F to +257°F (-40°C to +125°C) | DC | |
| 797TC-16-RL | 1008 in stock | 6653 in stock | $54.48/foot | FT | Rubber | 1 Inch | 6,000 psi (42 MPa) | 77 | Hose Products | > 5000 PSI (345 bar) | Tough Cover Constant Pressure 6000 PSI | Inch | GlobalCore | 6,000 psi (42 MPa) | ISO 18752 | Hydraulic | Inch | Fluid Connector | 6 1/2 Inch | High | 1 Inch | 77 | Hydraulic Industry Standard | 797TC | Rubber | -40°F to +257°F (-40°C to +125°C) | DC | ||||
| 797TC-20-BX | Backordered | Backordered | $114.46/foot | FT | Rubber | 1.25 Inch | 6,000 psi (42 MPa) | 77 | Hose Products | > 5000 PSI (345 bar) | Tough Cover Constant Pressure 6000 PSI | Inch | GlobalCore | 6,000 psi (42 MPa) | ISO 18752 | Hydraulic | Inch | Fluid Connector | 8 3/4 Inch | High | 1.25 Inch | 77 | Hydraulic Industry Standard | 797TC | Rubber | -40°F to +257°F (-40°C to +125°C) | DC | ||||
| 797TC-24-BX | Backordered | 75 in stock | $129.77/foot | FT | Rubber | 1.5 Inch | 6,000 psi (42 MPa) | 77 | Hose Products | > 5000 PSI (345 bar) | Tough Cover Constant Pressure 6000 PSI | Inch | GlobalCore | 6,000 psi (42 MPa) | ISO 18752 | Hydraulic | Inch | Fluid Connector | 12 Inch | High | 1.5 Inch | 77 | Hydraulic Industry Standard | 797TC | Rubber | -40°F to +257°F (-40°C to +125°C) | DC | ||||
| 797TC-32-BX | Backordered | 50 in stock | $170.62/foot | FT | Rubber | 2 Inch | 6,000 psi (42 MPa) | 77 | Hose Products | > 5000 PSI (345 bar) | Tough Cover Constant Pressure 6000 PSI | Inch | GlobalCore | 6,000 psi (42 MPa) | ISO 18752 | Hydraulic | Inch | Fluid Connector | 15 Inch | High | 2 Inch | 77 | Hydraulic Industry Standard | 797TC | Rubber | -40°F to +257°F (-40°C to +125°C) | DC | ||||
| 797TC-4-BX | Backordered | 30 in stock | $7.64/foot | FT | Rubber | 0.25 Inch | 6,000 psi (42 MPa) | 43 | Hose Products | > 5000 PSI (345 bar) | Tough Cover Constant Pressure 6000 PSI | Inch | GlobalCore | 6,000 psi (42 MPa) | ISO 18752 | Hydraulic | Inch | Fluid Connector | 2 Inch | High | 0.25 Inch | 43 | Hydraulic Industry Standard | 797TC | Rubber | -40°F to +212°F (-40°C to +100°C) | AC | ||||
| 797TC-4-RL | 1309 in stock | 29915 in stock | $6.16/foot | FT | Rubber | 0.25 Inch | 6,000 psi (42 MPa) | 43 | Hose Products | > 5000 PSI (345 bar) | Tough Cover Constant Pressure 6000 PSI | Inch | GlobalCore | 6,000 psi (42 MPa) | ISO 18752 | Hydraulic | Inch | Fluid Connector | 2 Inch | High | 0.25 Inch | 43 | Hydraulic Industry Standard | 797TC | Rubber | -40°F to +212°F (-40°C to +100°C) | AC | ||||
| 797TC-6-BX | Backordered | 52 in stock | $21.22/foot | FT | Rubber | 0.375 Inch | 6,000 psi (42 MPa) | 43 | Hose Products | > 5000 PSI (345 bar) | Tough Cover Constant Pressure 6000 PSI | Inch | GlobalCore | 6,000 psi (42 MPa) | ISO 18752 | Hydraulic | Inch | Fluid Connector | 2 1/2 Inch | High | 0.375 Inch | 43 | Hydraulic Industry Standard | 797TC | Rubber | -40°F to +212°F (-40°C to +100°C) | CC | ||||
| 797TC-6-RL | 1276 in stock | 7117 in stock | $17.14/foot | FT | Rubber | 0.375 Inch | 6,000 psi (42 MPa) | 43 | Hose Products | > 5000 PSI (345 bar) | Tough Cover Constant Pressure 6000 PSI | Inch | GlobalCore | 6,000 psi (42 MPa) | ISO 18752 | Hydraulic | Inch | Fluid Connector | 2 1/2 Inch | High | 0.375 Inch | 43 | Hydraulic Industry Standard | 797TC | Rubber | -40°F to +212°F (-40°C to +100°C) | CC | ||||
| 797TC-8-BX | Backordered | 48 in stock | $35.34/foot | FT | FT | Rubber | 0.5 Inch | 6,000 psi (42 MPa) | 43 | 50 | 50 FT | Hose Products | > 5000 PSI (345 bar) | Tough Cover Constant Pressure 6000 PSI | Inch | GlobalCore | 6,000 psi (42 MPa) | ISO 18752 | Hydraulic | Inch | Fluid Connector | 4 Inch | High | 0.5 Inch | 43 | Hydraulic Industry Standard | 797TC | Rubber | -40°F to +257°F (-40°C to +125°C) | DC | |
| 797TC-8-RL | 855 in stock | 7983 in stock | $28.55/foot | FT | Rubber | 0.5 Inch | 6,000 psi (42 MPa) | 43 | Hose Products | > 5000 PSI (345 bar) | Tough Cover Constant Pressure 6000 PSI | Inch | GlobalCore | 6,000 psi (42 MPa) | ISO 18752 | Hydraulic | Inch | Fluid Connector | 4 Inch | High | 0.5 Inch | 43 | Hydraulic Industry Standard | 797TC | Rubber | -40°F to +257°F (-40°C to +125°C) | DC |
