Picture of E-Z Form MP Oil Resistant Flexible Suction Hose, Multipurpose, Series 7219 - 7219-0625025

*PRODUCT IMAGE IS REPRESENTATIVE PROVIDED BY THE MANUFACTURER. DO NOT MAKE BUYING DECISIONS SOLEY BASED ON THE IMAGE. PLEASE VERIFY SPECIFICATIONS MEET YOUR REQUIREMENTS.

E-Z Form MP Oil Resistant Flexible Suction Hose, Multipurpose, Series 7219 - 7219-0625025

E-Z Form MP Greek Corrugated Multipurpose Oil Resistant Suction Hose is an extremely flexible hose designed for refined fuels and oil transfer in applications to 250°F and 75 psi, Series 7219
Availability:
43 in stock
Springfield, MO43
SKU 7219-0625025
$17.06
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options
Products specifications
Attribute nameAttribute value
UOMFTHose I.D. (inch)5/8
Standard Package Quantity25 ftDivisionHose Products Division
Specifications MetN/ADesign Factor4:1
MediaWaterCover ColorBlack
Maximum Operating Temperature121 °CInside Diameter15.9 mm
Hose Inner Tube MaterialBlackApplicationEngine
Weight0.37 lb/ftOutside Diameter1.1 inch
Cover MaterialChloroprene Rubber (CR)Minimum Operating Temperature-34 °C
Hose Reinforcement Material2 Plies of Textile with Wire HelixCompatible FittingHY
Minimum Bend Radius32.7 mmVacuum Pressure Rating737 mm-Hg
Maximum Operating Pressure0.5 MPa
