FF-1002-16FO - Flat Face, HTMA, Hydraulic Quick Couplings - FF and FC Series

Parker's non-spill, flat face hydraulic couplers and nipples are ideal for use across a variety of hydraulic applications where fluid lines require fast and easy connection and disconnection with minimal spillage and limited air inclusion

Availability:	Backordered Estimated Lead Time: 12 days
Partner Available:	6 in stock

SKU FF-1002-16FO

$230.78/each

Bypass upcharge for backordered quantity. Check this box if you prefer to backorder out of stock quantities from Hyspeco for this item, then click Add To Cart.

Products specifications

Attribute name	Attribute value
UOM	EA	Coupling Half	Male Nipple
Interchange Type	na	Body Size (inch)	1
Connection Thread Size (inch)	1 5/16 - 12	Connection Type	Female UNF
Maximum Operating Pressure	3000	Flow Rate	50 Gal/min
Hex Size	1.87 inch	Dimensional Weight	0.6232014388489209 lb
Seal Material	Nitrile	Minimum Operating Temperature	-40 °F
Body Material	Steel	Maximum Operating Temperature	250 °F
Valve Type	Non-spill	Plating Type	Zinc with clear trivalent chromate

Product resources

Compliance, Certifications & Safety

Safety Guide: Quick Couplings and Related Accessories (PDF)

Literature and Reference Materials
