Picture of Flow Control Valve - 3250 Series - 032501000

*PRODUCT IMAGE IS REPRESENTATIVE PROVIDED BY THE MANUFACTURER. DO NOT MAKE BUYING DECISIONS SOLEY BASED ON THE IMAGE. PLEASE VERIFY SPECIFICATIONS MEET YOUR REQUIREMENTS.

Flow Control Valve - 3250 Series - 032501000

The 3250 series flow control valves are designed to accurately meter the flow of air with large port sizes up to 1-1/2" NPT and flows of 1800 SCFM. Each valve has a fine screw adjustment, allowing precise settings that are secured by a sturdy lock nut.
Availability:
Backordered
SKU 032501000
$378.70
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options
Products specifications
Attribute nameAttribute value
UOMEAPort Size (inch)1
Port TypeNPTFDivisionPneumatic Division
MediaAirProduct TypeFlow Control
OptionsExtended Temperature VersionLubricantNone
Mounting TypeInlineNeedle MaterialStainless Steel
Port ConnectionFemale to FemaleFlow Rate1000
Port Size1"Port TypeNPTF
Body MaterialBrass or Cast AluminumSeal MaterialBuna N<br>Urethane
Flow Coefficient-Operating Pressure0 - 250
Operating Temperature-40° to +82°Operation TypeMeter Screw, Screw Drive Flat
Product resources

Literature and Reference Materials
