387-4 - Hydraulic Constant Working Pressure Hose 3000 PSI - GlobalCore 387 Hose

Part of Parker’s GlobalCore constant working pressure hose line, lightweight and flexible 387 hoses consistently deliver 3,000 PSI performance across markets and across the globe.

Availability:	Backordered
Partner Available:	890 in stock

SKU 387-4

$4.47/foot

Bypass upcharge for backordered quantity. Check this box if you prefer to backorder out of stock quantities from Hyspeco for this item, then click Add To Cart.

Products specifications

Attribute name	Attribute value
UOM	FT	Hose I.D. (size)	-4
Hose Cover Type	Standard Cover	Minimum Operating Temperature	-40 °F
Disclaimer	The user, through its own analysis and testing, is solely responsible for making the final selection of the system and components and assuring that all performance, endurance, maintenance, safety and warning requirements of the application are met.	Maximum Operating Pressure	3000 psi
Size	-4	Inside Diameter	1/4 inch
Maximum Operating Temperature	100 °C	Minimum Bend Radius	2 inch
Cover Material	Synthetic Rubber	Hose Cover Type	Standard Cover
Compatible Fitting	43 Series	Hose Inner Tube Material	Synthetic Rubber
Hose Reinforcement Material	1 Braid of Steel Wire	Nominal Hose Inside Diameter	6 mm
Media	Lubricants	Outside Diameter	13.4 mm
Weight	0.24 kg/m	Specifications Met	ISO 18752, Type AC
