797ST-12 - Hydraulic Constant Working Pressure Hose 6000 PSI - GlobalCore 797 Hose

Part of the GlobalCore line of robust yet lightweight hydraulic hose, Parker’s 797 hose is an easy-to-bend, easier-to-install 6000 PSI constant working pressure hose.

Availability:	Backordered Estimated Lead Time: 19 days
Partner Available:	849 in stock

SKU 797ST-12

$57.60/foot

Bypass upcharge for backordered quantity. Check this box if you prefer to backorder out of stock quantities from Hyspeco for this item, then click Add To Cart.

Products specifications

Attribute name	Attribute value
UOM	FT	Hose Cover Type	SuperTough
Hose I.D. (size)	-12	Hose Reinforcement Material	4 or 6 Spirals of Steel Wire
Inside Diameter	3/4 inch	Size	-12
Minimum Bend Radius	5-1/4 inch	Weight	1.16 kg/m
Minimum Operating Temperature	-40 °C	Maximum Operating Temperature	257 °F
Cover Material	Synthetic Rubber Abrasion Resistant	Media	Lubricants
Specifications Met	ISO 18752, Type DC	Outside Diameter	1.1 inch
Hose Inner Tube Material	Proprietary Synthetic Rubber Compound	Nominal Hose Inside Diameter	19 mm
Compatible Fitting	77 Series	Maximum Operating Pressure	42 MPa
