NS-502-10FO - Non-Spill, Flat Face, Push to Connect Quick Couplings with Sleeve Lock - NS Series

Name: NS-502-10FO - Non-Spill, Flat Face, Push to Connect Quick Couplings with Sleeve Lock - NS Series
SKU: NS-502-10FO
Price: 53.71 USD
Availability: InStock

Parker's non-spill, flat face hydraulic couplers are ideal for use across a variety of hydraulic applications where fluid lines require fast and easy connection and disconnection with minimal spillage and limited air inclusion.

Availability:

4 in stock

Kansas City, KS

Partner Available:

16 in stock

Quantities sourced from Partner Network will incur a 30% upcharge from the displayed price. Unit prices will be adjusted accordingly when these quantities are added to your cart.

SKU NS-502-10FO

$53.71/each

Qty:

Bypass upcharge for backordered quantity. Check this box if you prefer to backorder out of stock quantities from Hyspeco for this item, then click Add To Cart.

Products specifications

Attribute name	Attribute value
UOM	EA	Body Size (inch)	1/2
Connection Type	Female ORB	Connection Thread Size (inch)	7/8 - 14
Coupling Half	Male Nipple	Seal Material	Nitrile
Dimensional Weight	0.05341726618705036 lb	Flow Rate	12 Gal/min
Maximum Operating Pressure	2500 psi	Hex Size	1.06 inch
Plating Type	Zinc with clear trivalent chromate	Valve Type	Non-spill
Maximum Operating Temperature	250 °F	Minimum Operating Temperature	-40 °F
Body Material	Steel

Product resources

Compliance, Certifications & Safety

Safety Guide: Quick Couplings and Related Accessories (PDF)

Literature and Reference Materials
