Replacement Elements - Medium Pressure Filter 15/40/80 CN Series

*PRODUCT IMAGE IS REPRESENTATIVE PROVIDED BY THE MANUFACTURER. DO NOT MAKE BUYING DECISIONS SOLEY BASED ON THE IMAGE. PLEASE VERIFY SPECIFICATIONS MEET YOUR REQUIREMENTS.

The Parker CN Series is a compact, cost effective, medium pressure filter designed with Microglass filtration technology. CN Series replacement elements feature coreless construction. The design reduces solid waste and minimizes disposal costs for industry.

Using Parker CN Series replacement elements guarantees Parker’s quality of filtration, directly impacting the fluid cleanliness levels. Using aftermarket filters with unknown media quality may save initial cost, but can increase overall costs by requiring more element change outs and potentially causing system downtime. Protect your investment by always buying genuine Parker replacement elements.

Available in Single, Double and Triple lengths (40 CN only) and several micron ratings (2, 5, 10, and 20), these replacement elements ensure the quality of filtration Parker is known for. For ordering, please refer to the “How to Order” section of the literature or contact a Parker Representative.

View as Grid List

Sort by

Display per page

SKU	Availability	Partner Available	Price	UOM	UOM	Filter Element	Seal Material	Length	Filter Housing Series	For Fluid Type	Filter Element Type	Pkg Qty	Seals	Efficiency βx(C) ≥ 200	Efficiency βx(C) ≥ 1000	Media	Media Type	Collapse Pressure (bar)	Collapse Pressure (psi)	Parker Group	Parker Division	Operating Temperature	Element Length	Filter Media Code	Series	Seals	Efficiency βx(C) ≥ 200	Efficiency βx(C) ≥ 1000	Media	Media Type	Top Endcap Material	Bottom Endcap Material	Collapse Pressure (bar)	Collapse Pressure (psi)	Media Composition Detail	Glue Side Seam Adhesive	Glue Endcaps Adhesive	B Dimension	D Dimension	E Dimension	Competitor
936601Q	2 Limited Stock	132 in stock	$99.78/each	EA	EA	10Q Microglass	Fluorocarbon	single	40CN2	Mineral, Petroleum and Polyalphaolefin (PAO) based fluids	Coreless	1	FKM: Fluorocarbon	9 µ	12 µ	10 Micron Absolute	Microglass	10.3 bar	150 psi	Filtration	Hydraulic Filter	-40F to 225F (-40C to 107C)	Double	10QE	ParFit	FKM: Fluorocarbon	9 µ	12 µ	10 Micron Absolute	Microglass	Glass reinforced nylon	Glass reinforced nylon	10.3 bar	150 psi	Multilayer fiberglass with PBT mesh on both sides	Polyurethane	Polyurethane	1.693 in (43 mm)	0.315 in (8 mm)	8.386 in (213 mm)
936602Q	2 Limited Stock	22 in stock	$134.86/each	EA	EA	10Q Microglass	Fluorocarbon	single	80CN1	Mineral, Petroleum and Polyalphaolefin (PAO) based fluids	Coreless	1	FKM: Fluorocarbon	9 µ	12 µ	10 Micron Absolute	Microglass	10.3 bar	150 psi	Filtration	Hydraulic Filter	-40F to 225F (-40C to 107C)	Single	10QE	ParFit	FKM: Fluorocarbon	9 µ	12 µ	10 Micron Absolute	Microglass	Glass reinforced nylon	Glass reinforced nylon	10.3 bar	150 psi	Multilayer fiberglass with PBT mesh on both sides	Polyurethane	Polyurethane	2.205 in (56 mm)	3.799 in (96.5 mm)	8.449 in (214.6 mm)
936622Q	Backordered	7 in stock	$135.69/each	EA	EA	02Q Microglass	Fluorocarbon	double	40CN3	Mineral, Petroleum and Polyalphaolefin (PAO) based fluids	Coreless	1	FKM: Fluorocarbon	4 µ	5 µ	2 Micron Absolute	Microglass	10.3 bar	150 psi	Filtration	Hydraulic Filter	-40F to 225F (-40C to 107C)	Triple	02QE	ParFit	FKM: Fluorocarbon	4 µ	5 µ	2 Micron Absolute	Microglass	Glass reinforced nylon	Glass reinforced nylon	10.3 bar	150 psi	Multilayer fiberglass with PBT mesh on both sides	Polyurethane	Polyurethane	1.693 in (43 mm)	0.315 in (8 mm)	13.11 in (333 mm)
936623Q	Backordered	5 in stock	$130.19/each	EA	EA	05Q Microglass	Fluorocarbon	double	40CN3	Mineral, Petroleum and Polyalphaolefin (PAO) based fluids	Coreless	1	FKM: Fluorocarbon	5 µ	7 µ	5 Micron Absolute	Microglass	10.3 bar	150 psi	Filtration	Hydraulic Filter	-40F to 225F (-40C to 107C)	Triple	05QE	ParFit	FKM: Fluorocarbon	5 µ	7 µ	5 Micron Absolute	Microglass	Glass reinforced nylon	Glass reinforced nylon	10.3 bar	150 psi	Multilayer fiberglass with PBT mesh on both sides	Polyurethane	Polyurethane	1.693 in (43 mm)	0.315 in (8 mm)	13.11 in (333 mm)
936698Q	3 in stock	45 in stock	$57.36/each	EA	EA	02Q Microglass	Fluorocarbon	single	15CN1	Mineral, Petroleum and Polyalphaolefin (PAO) based fluids	Coreless	1	FKM: Fluorocarbon	4 µ	5 µ	2 Micron Absolute	Microglass	10.3 bar	150 psi	Filtration	Hydraulic Filter	-40F to 225F (-40C to 107C)	Single	02QE	ParFit	FKM: Fluorocarbon	4 µ	5 µ	2 Micron Absolute	Microglass	Glass reinforced nylon	Glass reinforced nylon	10.3 bar	150 psi	Multilayer fiberglass with PBT mesh on both sides	Polyurethane	Polyurethane	1 in (25.4 mm)	1.772 in (45 mm)	4.598 in (116.8 mm)
936699Q	1 Limited Stock	44 in stock	$52.60/each	EA	EA	05Q Microglass	Fluorocarbon	single	15CN1	Mineral, Petroleum and Polyalphaolefin (PAO) based fluids	Coreless	1	FKM: Fluorocarbon	5 µ	7 µ	5 Micron Absolute	Microglass	10.3 bar	150 psi	Filtration	Hydraulic Filter	-40F to 225F (-40C to 107C)	Single	05QE	ParFit	FKM: Fluorocarbon	5 µ	7 µ	5 Micron Absolute	Microglass	Glass reinforced nylon	Glass reinforced nylon	10.3 bar	150 psi	Multilayer fiberglass with PBT mesh on both sides	Polyurethane	Polyurethane	1 in (25.4 mm)	1.772 in (45 mm)	4.598 in (116.8 mm)
936700Q	1 Limited Stock	117 in stock	$49.56/each	EA	EA	10Q Microglass	Fluorocarbon	single	15CN1	Mineral, Petroleum and Polyalphaolefin (PAO) based fluids	Coreless	1	FKM: Fluorocarbon	9 µ	12 µ	10 Micron Absolute	Microglass	10.3 bar	150 psi	Filtration	Hydraulic Filter	-40F to 225F (-40C to 107C)	Single	10QE	ParFit	FKM: Fluorocarbon	9 µ	12 µ	10 Micron Absolute	Microglass	Glass reinforced nylon	Glass reinforced nylon	10.3 bar	150 psi	Multilayer fiberglass with PBT mesh on both sides	Polyurethane	Polyurethane	1 in (25.4 mm)	1.772 in (45 mm)	4.598 in (116.8 mm)
936701Q	Backordered	49 in stock	$49.31/each	EA	EA	20Q Microglass	Fluorocarbon	single	15CN1	Mineral, Petroleum and Polyalphaolefin (PAO) based fluids	Coreless	1	FKM: Fluorocarbon	16 µ	20 µ	20 Micron Absolute	Microglass	10.3 bar	150 psi	Filtration	Hydraulic Filter	-40F to 225F (-40C to 107C)	Single	20QE	ParFit	FKM: Fluorocarbon	16 µ	20 µ	20 Micron Absolute	Microglass	Glass reinforced nylon	Glass reinforced nylon	10.3 bar	150 psi	Multilayer fiberglass with PBT mesh on both sides	Polyurethane	Polyurethane	1 in (25.4 mm)	1.772 in (45 mm)	4.598 in (116.8 mm)
936702Q	Backordered	11 in stock	$74.07/each	EA	EA	02Q Microglass	Fluorocarbon	double	15CN2	Mineral, Petroleum and Polyalphaolefin (PAO) based fluids	Coreless	1	FKM: Fluorocarbon	4 µ	5 µ	2 Micron Absolute	Microglass	10.3 bar	150 psi	Filtration	Hydraulic Filter	-40F to 225F (-40C to 107C)	Double	02QE	ParFit	FKM: Fluorocarbon	4 µ	5 µ	2 Micron Absolute	Microglass	Glass reinforced nylon	Glass reinforced nylon	10.3 bar	150 psi	Multilayer fiberglass with PBT mesh on both sides	Polyurethane	Polyurethane	1 in (25.4 mm)	1.772 in (45 mm)	0.858 in (21.8 mm)
936703Q	2 Limited Stock	54 in stock	$67.20/each	EA	EA	05Q Microglass	Fluorocarbon	double	15CN2	Mineral, Petroleum and Polyalphaolefin (PAO) based fluids	Coreless	1	FKM: Fluorocarbon	5 µ	7 µ	5 Micron Absolute	Microglass	10.3 bar	150 psi	Filtration	Hydraulic Filter	-40F to 225F (-40C to 107C)	Double	05QE	ParFit	FKM: Fluorocarbon	5 µ	7 µ	5 Micron Absolute	Microglass	Glass reinforced nylon	Glass reinforced nylon	10.3 bar	150 psi	Multilayer fiberglass with PBT mesh on both sides	Polyurethane	Polyurethane	1 in (25.4 mm)	1.772 in (45 mm)	0.858 in (21.8 mm)
936704Q	2 Limited Stock	97 in stock	$62.51/each	EA	EA	10Q Microglass	Fluorocarbon	double	15CN2	Mineral, Petroleum and Polyalphaolefin (PAO) based fluids	Coreless	1	FKM: Fluorocarbon	9 µ	12 µ	10 Micron Absolute	Microglass	10.3 bar	150 psi	Filtration	Hydraulic Filter	-40F to 225F (-40C to 107C)	Double	10QE	ParFit	FKM: Fluorocarbon	9 µ	12 µ	10 Micron Absolute	Microglass	Glass reinforced nylon	Glass reinforced nylon	10.3 bar	150 psi	Multilayer fiberglass with PBT mesh on both sides	Polyurethane	Polyurethane	1 in (25.4 mm)	1.772 in (45 mm)	0.858 in (21.8 mm)	HY-PRO
936705Q	11 in stock	63 in stock	$62.25/each	EA	EA	20Q Microglass	Fluorocarbon	double	15CN2	Mineral, Petroleum and Polyalphaolefin (PAO) based fluids	Coreless	1	FKM: Fluorocarbon	16 µ	20 µ	20 Micron Absolute	Microglass	10.3 bar	150 psi	Filtration	Hydraulic Filter	-40F to 225F (-40C to 107C)	Double	20QE	ParFit	FKM: Fluorocarbon	16 µ	20 µ	20 Micron Absolute	Microglass	Glass reinforced nylon	Glass reinforced nylon	10.3 bar	150 psi	Multilayer fiberglass with PBT mesh on both sides	Polyurethane	Polyurethane	1 in (25.4 mm)	1.772 in (45 mm)	0.858 in (21.8 mm)	HY-PRO
936706Q	Backordered	7 in stock	$87.31/each	EA	EA	02Q Microglass	Fluorocarbon	triple	40CN1	Mineral, Petroleum and Polyalphaolefin (PAO) based fluids	Coreless	1	FKM: Fluorocarbon	4 µ	5 µ	2 Micron Absolute	Microglass	10.3 bar	150 psi	Filtration	Hydraulic Filter	-40F to 225F (-40C to 107C)	Single	02QE	ParFit	FKM: Fluorocarbon	4 µ	5 µ	2 Micron Absolute	Microglass	Glass reinforced nylon	Glass reinforced nylon	10.3 bar	150 psi	Multilayer fiberglass with PBT mesh on both sides	Polyurethane	Polyurethane	1.693 in (43 mm)	0.315 in (8 mm)	4.606 in (117 mm)
936707Q	1 Limited Stock	13 in stock	$81.14/each	EA	EA	05Q Microglass	Fluorocarbon	triple	40CN1	Mineral, Petroleum and Polyalphaolefin (PAO) based fluids	Coreless	1	FKM: Fluorocarbon	5 µ	7 µ	5 Micron Absolute	Microglass	10.3 bar	150 psi	Filtration	Hydraulic Filter	-40F to 225F (-40C to 107C)	Single	05QE	ParFit	FKM: Fluorocarbon	5 µ	7 µ	5 Micron Absolute	Microglass	Glass reinforced nylon	Glass reinforced nylon	10.3 bar	150 psi	Multilayer fiberglass with PBT mesh on both sides	Polyurethane	Polyurethane	1.693 in (43 mm)	0.315 in (8 mm)	4.606 in (117 mm)
936708Q	4 in stock	125 in stock	$77.78/each	EA	EA	10Q Microglass	Fluorocarbon	triple	40CN1	Mineral, Petroleum and Polyalphaolefin (PAO) based fluids	Coreless	1	FKM: Fluorocarbon	9 µ	12 µ	10 Micron Absolute	Microglass	10.3 bar	150 psi	Filtration	Hydraulic Filter	-40F to 225F (-40C to 107C)	Single	10QE	ParFit	FKM: Fluorocarbon	9 µ	12 µ	10 Micron Absolute	Microglass	Glass reinforced nylon	Glass reinforced nylon	10.3 bar	150 psi	Multilayer fiberglass with PBT mesh on both sides	Polyurethane	Polyurethane	1.693 in (43 mm)	0.315 in (8 mm)	4.606 in (117 mm)	DONALDSON
936709Q	1 Limited Stock	26 in stock	$70.01/each	EA	EA	20Q Microglass	Fluorocarbon	triple	40CN1	Mineral, Petroleum and Polyalphaolefin (PAO) based fluids	Coreless	1	FKM: Fluorocarbon	16 µ	20 µ	20 Micron Absolute	Microglass	10.3 bar	150 psi	Filtration	Hydraulic Filter	-40F to 225F (-40C to 107C)	Single	20QE	ParFit	FKM: Fluorocarbon	16 µ	20 µ	20 Micron Absolute	Microglass	Glass reinforced nylon	Glass reinforced nylon	10.3 bar	150 psi	Multilayer fiberglass with PBT mesh on both sides	Polyurethane	Polyurethane	1.693 in (43 mm)	0.315 in (8 mm)	4.606 in (117 mm)
936710Q	3 in stock	52 in stock	$110.38/each	EA	EA	02Q Microglass	Fluorocarbon	single	40CN2	Mineral, Petroleum and Polyalphaolefin (PAO) based fluids	Coreless	1	FKM: Fluorocarbon	4 µ	5 µ	2 Micron Absolute	Microglass	10.3 bar	150 psi	Filtration	Hydraulic Filter	-40F to 225F (-40C to 107C)	Double	02QE	ParFit	FKM: Fluorocarbon	4 µ	5 µ	2 Micron Absolute	Microglass	Glass reinforced nylon	Glass reinforced nylon	10.3 bar	150 psi	Multilayer fiberglass with PBT mesh on both sides	Polyurethane	Polyurethane	1.693 in (43 mm)	0.315 in (8 mm)	8.386 in (213 mm)
936711Q	Backordered	65 in stock	$103.61/each	EA	EA	05Q Microglass	Fluorocarbon	single	40CN2	Mineral, Petroleum and Polyalphaolefin (PAO) based fluids	Coreless	1	FKM: Fluorocarbon	5 µ	7 µ	5 Micron Absolute	Microglass	10.3 bar	150 psi	Filtration	Hydraulic Filter	-40F to 225F (-40C to 107C)	Double	05QE	ParFit	FKM: Fluorocarbon	5 µ	7 µ	5 Micron Absolute	Microglass	Glass reinforced nylon	Glass reinforced nylon	10.3 bar	150 psi	Multilayer fiberglass with PBT mesh on both sides	Polyurethane	Polyurethane	1.693 in (43 mm)	0.315 in (8 mm)	8.386 in (213 mm)
936712Q	Backordered	65 in stock	$121.58/each	EA	EA	20Q Microglass	Fluorocarbon	single	40CN2	Mineral, Petroleum and Polyalphaolefin (PAO) based fluids	Coreless	1	FKM: Fluorocarbon	16 µ	20 µ	20 Micron Absolute	Microglass	10.3 bar	150 psi	Filtration	Hydraulic Filter	-40F to 225F (-40C to 107C)	Double	20QE	ParFit	FKM: Fluorocarbon	16 µ	20 µ	20 Micron Absolute	Microglass	Glass reinforced nylon	Glass reinforced nylon	10.3 bar	150 psi	Multilayer fiberglass with PBT mesh on both sides	Polyurethane	Polyurethane	1.693 in (43 mm)	0.315 in (8 mm)	8.386 in (213 mm)
936713Q	Backordered	Backordered	$153.35/each	EA	EA	02Q Microglass	Fluorocarbon	single	80CN1	Mineral, Petroleum and Polyalphaolefin (PAO) based fluids	Coreless	1	FKM: Fluorocarbon	4 µ	5 µ	2 Micron Absolute	Microglass	10.3 bar	150 psi	Filtration	Hydraulic Filter	-40F to 225F (-40C to 107C)	Single	02QE	ParFit	FKM: Fluorocarbon	4 µ	5 µ	2 Micron Absolute	Microglass	Glass reinforced nylon	Glass reinforced nylon	10.3 bar	150 psi	Multilayer fiberglass with PBT mesh on both sides	Polyurethane	Polyurethane	2.205 in (56 mm)	3.799 in (96.5 mm)	8.449 in (214.6 mm)
