Union Elbow 255IFHD
*PRODUCT IMAGE IS REPRESENTATIVE PROVIDED BY THE MANUFACTURER. DO NOT MAKE BUYING DECISIONS SOLEY BASED ON THE IMAGE. PLEASE VERIFY SPECIFICATIONS MEET YOUR REQUIREMENTS.
Parker 45° inverted flare fittings meet the functional requirements of SAE J512 and are listed with Underwriter’s Laboratories. For use with copper, brass, aluminum or steel tubing that can be flared to 45°.
Read More...| Action | SKU | Availability | Partner Available | Price | UOM | UOM | Material | Pkg Qty | Outer Diameter 1 | Outer Diameter 2 | Thread 1 | Thread 2 | Parker Group | Inch/Metric | Material | Parker Division | Outer Diameter 1 Inch/mm | Configuration Type | Thread 1 Type | Operating Temperature | Thread 2 Type | Outer Diameter 2 Inch/mm | Outer Diameter 1 | Outer Diameter 2 | Series | Thread 1 | Thread 2 | Configuration Sub-Type | Pressure Rating | SAE Compliance | SAE Reference | Body Shape |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 255IFHD-4 | Backordered | 3 in stock | $18.60/each | EA | EA | Brass | 1 | 1/4 Inch | 1/4 Inch | 7/16-24 UN/UNF | 7/16-24 UN/UNF | Fluid Connector | Inch | Brass | Fluid Systems Connector (Brass Products) | Inch | Flare to Flare | UN/UNF | -65°F to +250°F | UN/UNF | Inch | 1/4 Inch | 1/4 Inch | 45° Inverted Flare | 7/16-24 UN/UNF | 7/16-24 UN/UNF | Union Elbow 90° | 1400 PSI | J512 | SAE 040427 | Extruded |
