MPT® II NONCONDUCTIVE MULTIPURPOSE OIL RESISTANT HOSE

*PRODUCT IMAGE IS REPRESENTATIVE PROVIDED BY THE MANUFACTURER. DO NOT MAKE BUYING DECISIONS SOLEY BASED ON THE IMAGE. PLEASE VERIFY SPECIFICATIONS MEET YOUR REQUIREMENTS.

Parker's MPT II Nonconductive Multipurpose Oil Resistant Hose provides excellent service across multiple applications. The hose is electrically nonconductive, protecting operators from electrical shock. The red cover is easily identified and is resistant to abrasion, oil and weathering to provide maximum performance. MPT II hose is available in long continuous lengths for efficient inventory management and maximum utility at cramped or hard to reach job sites. The hose is qualified with permanent crimp couplings for a safe and secure connection and is a versatile hose for many common industrial applications.

Markets:

• Agriculture

• Construction

• General Industrial

Features/Benefits:

• Tube: Black nitrile for oil compatibility and versatile service to 212°F.

• Reinforcement: Multiple textile plies for strength and kink resistance.

• Cover: Black or red chloroprene for abrasion, oil and weathering resistance.

• Couplings: Qualified with steel crimp couplings for a durable, safe and secure connection.

Applications:

• Air

• Oil

• Mild chemicals

• Water

• Air compressors and pneumatic tools, including those subject to light oil mists for lubrication

• Lubrication systems

• General transfer

Safety/Technical:

• Design Factor 4:1

• Do not use with biodiesel, diesel fuel or gasoline.

• Do not use in dry air applications (typically, air systems that do not expose the tube of the hose to lubricating oil mist from the compressor).

• The user must determine if the hose is suitable for applications subject to electrical hazard. Contact us for additional information.

• Refer to CrimpSource® for current crimp specifications.

Warnings:

• Couplings attached with bands or clamps may reduce the working pressure of the hose assembly to less than the maximum rated working pressure of the hose. Refer to NAHAD Industrial Hose Assembly Guidelines.

View as Grid List

Sort by

Display per page

SKU	Availability	Partner Available	Price	UOM	UOM	Color	Hose I.D. (inch)	Maximum Working Pressure (psi)	Packaging	Specifications Met	Maximum Operating Pressure	Inside Diameter	Size	Media	Outside Diameter	Nominal Hose Inside Diameter	Weight	Hose Reinforcement Material	Cover Material	Minimum Bend Radius	Hose Inner Tube Material	Maximum Operating Temperature	Minimum Operating Temperature	Inner Diameter	Pkg Qty	Color	Pkg Qty/UOM	Working Pressure	Mating Fitting Series	Package Type	Parker Group	Inch/Metric	Parker Division	Inner Diameter	Inner Diameter Inch/mm	Color	Hose Pressure Range	Mating End Fitting Series	Series	Trade Name	Hose Category
7094-100200	Backordered	915 in stock	$5.67/foot	FT	FT	Red	1	200	Reels	N/A	1.4 MPa	25.4 mm	-16	Mild Chemicals - Check your fluid compatibility with our catalogue chart.	1.410 inch	25 mm	0.49 lb/ft	Mutiple Plies of Textile	Chloroprene Rubber (CR)	254 mm	ARPM Class A Oil Resistance	212 °F (Other Media)	-29 °C	1 Inch	300	Red	300 FT	200 PSI (14 bar)	HY	Reel	Fluid Connector	Inch	Hose Products	1 Inch	Inch	Red	Low	HY	7094	MPT® II	Multipurpose Oil Resistant
7094-100304	1605 in stock	3557 in stock	$7.94/foot	FT	FT	Red	1	300	Reels	N/A	2.1 MPa	1 inch	-16	Air	1.440 inch	25 mm	0.54 lb/ft	Mutiple Plies of Textile	Chloroprene Rubber (CR)	8 inch	Nitrile	70 °C (Air)	-20 °F	1 Inch	300	Red	300 FT	300 PSI (20 bar)	HY	Reel	Fluid Connector	Inch	Hose Products	1 Inch	Inch	Red	Low	HY	7094	MPT® II	Multipurpose Oil Resistant
7094-125204	2 Limited Stock	920 in stock	$12.29/foot	FT	FT	Red	1-1/4	200	Reels	N/A	13.8 bar	1-1/4 inch	-20	Air	1.780 inch	32 mm	1.22 kg/m	Mutiple Plies of Textile	Chloroprene Rubber (CR)	228.6 mm	ARPM Class A Oil Resistance	70 °C (Air)	-20 °F	1.25 Inch	250	Red	250 FT	200 PSI (14 bar)	HY	Reel	Fluid Connector	Inch	Hose Products	1.25 Inch	Inch	Red	Low	HY	7094	MPT® II	Multipurpose Oil Resistant
7094-150204	195 in stock	915 in stock	$14.34/foot	FT	FT	Red	1-1/2	200	Reels	N/A	13.8 bar	38.1 mm	-24	Lubricants (Oils)	2.030 inch	40 mm	1.34 kg/m	Mutiple Plies of Textile	Chloroprene Rubber (CR)	254 mm	Nitrile	158 °F (Air)	-20 °F	1.5 Inch	200	Red	200 FT	200 PSI (14 bar)	43	Reel	Fluid Connector	Inch	Hose Products	1.5 Inch	Inch	Red	Low	43	7094	MPT® II	Multipurpose Oil Resistant
7094-25200	Backordered	848 in stock	$1.52/foot	FT	FT	Red	1/4	200	Reels	N/A	200 psi	6.4 mm	-4	Mild Chemicals - Check your fluid compatibility with our catalogue chart.	12.7 mm	8 mm	0.1 lb/ft	Mutiple Plies of Textile	Chloroprene Rubber (CR)	2 inch	ARPM Class A Oil Resistance	158 °F (Air)	-29 °C	0.25 Inch	800	Red	800 FT	200 PSI (14 bar)	HY	Reel	Fluid Connector	Inch	Hose Products	0.25 Inch	Inch	Red	Low	HY	7094	MPT® II	Multipurpose Oil Resistant
7094-25300	150 in stock	729 in stock	$2.04/foot	FT	FT	Red	1/4	300	Reels	N/A	300 psi	6.4 mm	-4	Mild Chemicals - Check your fluid compatibility with our catalogue chart.	0.550 inch	8 mm	0.18 kg/m	Mutiple Plies of Textile	Chloroprene Rubber (CR)	2.5 inch	Black	212 °F (Other Media)	-20 °F	0.25 Inch	800	Red	800 FT	300 PSI (20 bar)	HY	Reel	Fluid Connector	Inch	Hose Products	0.25 Inch	Inch	Red	Low	HY	7094	MPT® II	Multipurpose Oil Resistant
7094-31300	20 in stock	4472 in stock	$2.06/foot	FT	FT	Red	5/16	300	Reels	N/A	2.1 MPa	7.9 mm	-5	Water	0.590 inch	n/a	0.13 lb/ft	Mutiple Plies of Textile	Chloroprene Rubber (CR)	83.8 mm	Black	158 °F (Air)	-29 °C	0.313 Inch	750	Red	750 FT	300 PSI (20 bar)	HY	Reel	Fluid Connector	Inch	Hose Products	0.313 Inch	Inch	Red	Low	HY	7094	MPT® II	Multipurpose Oil Resistant
7094-38200	Backordered	1786 in stock	$2.06/foot	FT	FT	Red	3/8	200	Reels	N/A	200 psi	3/8 inch	-6	Mild Chemicals - Check your fluid compatibility with our catalogue chart.	16.7 mm	10 mm	0.15 lb/ft	Mutiple Plies of Textile	Chloroprene Rubber (CR)	3.8 inch	Black	70 °C (Air)	-29 °C	0.375 Inch	700	Red	700 FT	200 PSI (14 bar)	HY	Reel	Fluid Connector	Inch	Hose Products	0.375 Inch	Inch	Red	Low	HY	7094	MPT® II	Multipurpose Oil Resistant
7094-38300	Backordered	1967 in stock	$2.46/foot	FT	FT	Red	3/8	300	Reels	N/A	2.1 MPa	9.5 mm	-6	Mild Chemicals - Check your fluid compatibility with our catalogue chart.	0.690 inch	10 mm	0.17 lb/ft	Mutiple Plies of Textile	Chloroprene Rubber (CR)	3.8 inch	Nitrile	158 °F (Air)	-20 °F	0.375 Inch	650	Red	650 FT	300 PSI (20 bar)	HY	Reel	Fluid Connector	Inch	Hose Products	0.375 Inch	Inch	Red	Low	HY	7094	MPT® II	Multipurpose Oil Resistant
7094-50200	Backordered	842 in stock	$2.47/foot	FT	FT	Red	1/2	200	Reels	N/A	13.8 bar	1/2 inch	-8	Mild Chemicals - Check your fluid compatibility with our catalogue chart.	0.810 inch	15 mm	0.21 lb/ft	Mutiple Plies of Textile	Chloroprene Rubber (CR)	127 mm	Nitrile	100 °C (Other Media)	-20 °F	0.5 Inch	550	Red	550 FT	200 PSI (14 bar)	HY	Reel	Fluid Connector	Inch	Hose Products	0.5 Inch	Inch	Red	Low	HY	7094	MPT® II	Multipurpose Oil Resistant
7094-50250	Backordered	2092 in stock	$3.02/foot	FT	FT	Red	1/2	250	Reels	N/A	250 psi	12.7 mm	-8	Mild Chemicals - Check your fluid compatibility with our catalogue chart.	21.4 mm	15 mm	0.22 lb/ft	Mutiple Plies of Textile	Chloroprene Rubber (CR)	5 inch	Nitrile	212 °F (Other Media)	-29 °C	0.5 Inch	550	Red	550 FT	250 PSI (17 bar)	HY	Reel	Fluid Connector	Inch	Hose Products	0.5 Inch	Inch	Red	Low	HY	7094	MPT® II	Multipurpose Oil Resistant
7094-50304	203 in stock	2732 in stock	$3.16/foot	FT	FT	Red	1/2	300	Reels	N/A	300 psi	12.7 mm	-8	Air	22.2 mm	15 mm	0.26 lb/ft	Mutiple Plies of Textile	Chloroprene Rubber (CR)	5 inch	Black	158 °F (Air)	-29 °C	0.5 Inch	500	Red	500 FT	300 PSI (20 bar)	HY	Reel	Fluid Connector	Inch	Hose Products	0.5 Inch	Inch	Red	Low	HY	7094	MPT® II	Multipurpose Oil Resistant
7094-63304	64 in stock	3856 in stock	$4.10/foot	FT	FT	Red	5/8	300	Reels	N/A	2.1 MPa	5/8 inch	-10	Mild Chemicals - Check your fluid compatibility with our catalogue chart.	1.060 inch	18 mm	0.57 kg/m	Mutiple Plies of Textile	Chloroprene Rubber (CR)	154.9 mm	Black	70 °C (Air)	-20 °F	0.625 Inch	450	Red	450 FT	300 PSI (20 bar)	HY	Reel	Fluid Connector	Inch	Hose Products	0.625 Inch	Inch	Red	Low	HY	7094	MPT® II	Multipurpose Oil Resistant
7094-75200	Backordered	480 in stock	$3.78/foot	FT	FT	Red	3/4	200	Reels	N/A	13.8 bar	3/4 inch	-12	Lubricants (Oils)	1.110 inch	20 mm	0.54 kg/m	Mutiple Plies of Textile	Chloroprene Rubber (CR)	7.5 inch	Nitrile	158 °F (Air)	-20 °F	0.75 Inch	400	Red	400 FT	200 PSI (14 bar)	HY	Reel	Fluid Connector	Inch	Hose Products	0.75 Inch	Inch	Red	Low	HY	7094	MPT® II	Multipurpose Oil Resistant
7094-75304	811 in stock	8519 in stock	$4.04/foot	FT	FT	Red	3/4	300	Reels	N/A	20.7 bar	3/4 inch	-12	Lubricants (Oils)	1.160 inch	20 mm	0.6 kg/m	Mutiple Plies of Textile	Chloroprene Rubber (CR)	6 inch	Nitrile	212 °F (Other Media)	-20 °F	0.75 Inch	400	Red	400 FT	300 PSI (20 bar)	HY	Reel	Fluid Connector	Inch	Hose Products	0.75 Inch	Inch	Red	Low	HY	7094	MPT® II	Multipurpose Oil Resistant
7095-100200	Backordered	32 in stock	$5.67/foot	FT	FT	Black	1	200	Reels	N/A	13.8 bar	1 inch	-16	Water	35.7 mm	25 mm	0.49 lb/ft	Mutiple Plies of Textile	Chloroprene Rubber (CR)	254 mm	Black	212 °F (Other Media)	-20 °F	1 Inch	300	Black	300 FT	200 PSI (14 bar)	HY	Reel	Fluid Connector	Inch	Hose Products	1 Inch	Inch	Black	Low	HY	7095	MPT® II	Multipurpose Oil Resistant
7095-100304	Backordered	1112 in stock	$7.94/foot	FT	FT	Black	1	300	Reels	N/A	300 psi	25.4 mm	-16	Mild Chemicals - Check your fluid compatibility with our catalogue chart.	36.5 mm	25 mm	0.54 lb/ft	Mutiple Plies of Textile	Chloroprene Rubber (CR)	203.2 mm	Nitrile	158 °F (Air)	-29 °C	1 Inch	300	Black	300 FT	300 PSI (20 bar)	HY	Reel	Fluid Connector	Inch	Hose Products	1 Inch	Inch	Black	Low	HY	7095	MPT® II	Multipurpose Oil Resistant
7095-25300	347 in stock	800 in stock	$2.04/foot	FT	FT	Black	1/4	300	Reels	N/A	300 psi	1/4 inch	-4	Water	14 mm	8 mm	0.12 lb/ft	Mutiple Plies of Textile	Chloroprene Rubber (CR)	2.5 inch	Black	100 °C (Other Media)	-29 °C	0.25 Inch	800	Black	800 FT	300 PSI (20 bar)	HY	Reel	Fluid Connector	Inch	Hose Products	0.25 Inch	Inch	Black	Low	HY	7095	MPT® II	Multipurpose Oil Resistant
7095-31300	Backordered	Backordered	$2.06/foot	FT	FT	Black	5/16	300	Reels	N/A	20.7 bar	5/16 inch	-5	Air	15.1 mm	n/a	0.13 lb/ft	Mutiple Plies of Textile	Chloroprene Rubber (CR)	3.3 inch	Black	70 °C (Air)	-20 °F	0.313 Inch	750	Black	750 FT	300 PSI (20 bar)	HY	Reel	Fluid Connector	Inch	Hose Products	0.313 Inch	Inch	Black	Low	HY	7095	MPT® II	Multipurpose Oil Resistant
7095-38200	26 in stock	2561 in stock	$2.06/foot	FT	FT	Black	3/8	200	Reels	N/A	1.4 MPa	9.5 mm	-6	Air	0.660 inch	10 mm	0.22 kg/m	Mutiple Plies of Textile	Chloroprene Rubber (CR)	96.5 mm	Nitrile	158 °F (Air)	-29 °C	0.375 Inch	700	Black	700 FT	200 PSI (14 bar)	HY	Reel	Fluid Connector	Inch	Hose Products	0.375 Inch	Inch	Black	Low	HY	7095	MPT® II	Multipurpose Oil Resistant
