24X429

Manufacturer: Graco

Availability:	Backordered Estimated Lead Time: 10 days
Partner Available:	Backordered

SKU 24X429

Products specifications

Attribute name	Attribute value
Series	205	Material	PTFE
Connection Type	Threaded	Type	Pneumatic
Maximum Flow Rate	2.5 GPM	Center Section Material	Polypropylene
Maximum Solid Size	0.06 Inch	Maximum Operating Temperature	212 deg F
Manifold Configuration	Center Port	Minimum Operating Temperature	32 deg F
Air Inlet Size	1/8 Inch	Fluid Outlet Thread Type	NPT
Fluid Inlet Size	1/4 Inch	Fluid Outlet Thread Gender	Female
Fluid Outlet Size	1/4 Inch	Fluid Inlet Thread Type	NPT
Minimum Storage Temperature	32 deg F	Maximum Air Consumption	4.8 SCFM
Air Inlet Thread Gender	Female	Air Inlet Thread Type	NPT
Model	ChemSafe	Fluid Inlet Thread Gender	Female
Maximum Cycle Rate	375 CPM
