21MPa Compact Design Hydraulic Cylinder Model:210S-1 - 210S-1-SKU

Name: 21MPa Compact Design Hydraulic Cylinder Model:210S-1 - 210S-1-SKU
SKU: 210S-1-SKU

Series 210S-1 Compact Hydraulic Cylinders – best choice when mounting space is at a premium and the application demands a high force cylinder at operating pressures up to 21 MPa.

Availability:

Backordered

SKU 210S-1-SKU

POR

Qty:

Products specifications

Attribute name	Attribute value
Fluid Type	Petroleum-based fluid(When using another fluid,give us such instructions.)	Screw Tolerance	JIS 6g/6H
Bore Diameter (mm)	32, 40, 50, 63, 80	Type	Double Acting Single Rod, Standard type
Body Material	Carbon steel for machine structural use	Minimum Operating Pressure (MPa)	0.3
Rod End Thread Type	Female thread and male thread	Cushioning Type	None
Seal Material	3:Fluorocarbon 6:HNBR	Speed Range	8-100mm/s
Mounting Style	SD	Proof Pressure (MPa)	31.5
Temperature Range (C)	-10-+120 (No freezing)	Nominal Pressure (MPa)	21
Stroke Length Tolerance (mm)	0-+0.8	Maximum Working Pressure (MPa)	21
Division	TAIYO Division
