*PRODUCT IMAGE IS REPRESENTATIVE PROVIDED BY THE MANUFACTURER. DO NOT MAKE BUYING DECISIONS SOLEY BASED ON THE IMAGE. PLEASE VERIFY SPECIFICATIONS MEET YOUR REQUIREMENTS.

22/23 Series - General Purpose Solenoid Valves - 06F23O2240A3F

Name: 22/23 Series - General Purpose Solenoid Valves - 06F23O2240A3F
SKU: 06F23O2240A3F

This series is general superseded by G7 Series 22/23 Valves.

Availability:

Backordered

SKU 06F23O2240A3F

POR

Qty:

Products specifications

Attribute name	Attribute value
Media	General Purpose	Function	Normally Open
Coil Type	Requires Coil from Chart 6	Port Size	3/8
Port Type	NPT	Installation	IOM 7321
Orifice Size	5/8	Body Material	BRASS
Input Voltage	Pressure Vessel Only	Seal Material	FKM
Actuation Type	Direct Lift	Insulation Class	N/A
Power Consumption	11.5	Specifications Met	N/A
Valve Configuration	2 Way	Main Flow Coefficient	3.0
Ingress Protection Rating	N/A	Maximum Fluid Temperature	150.0
Preventive Maintenance Kit	06F23O2240A3FR	Maximum Ambient Temperature	77.0
Maximum Pressure Differential	125 (80 Light Oil)	Minimum Pressure Differential	0.0
Media	General Purpose	Function	Normally Open
Coil Type	Requires Coil from Chart 6	Port Size	3/8 inch
Port Type	NPT	Installation	IOM 7321
Orifice Size	5/8 inch	Body Material	Brass
Input Voltage	Pressure Vessel Only	Seal Material	FKM
Actuation Type	Direct Lift	Insulation Class	N/A
Power Consumption	11.5 W	Specifications Met	N/A
Division	Fluid Control Division	Valve Configuration	2 Way
Main Flow Coefficient	3.0 Cv	Ingress Protection Rating	N/A
Maximum Fluid Temperature	150.0 °F	Preventive Maintenance Kit	06F23O2240A3FR
Maximum Ambient Temperature	77.0 °F	Maximum Pressure Differential	125 (80 Light Oil) psi
Minimum Pressure Differential	0.0 psi

Product resources

Literature and Reference Materials

Tube Seal (PDF)
