| Flow Rate | 20 GAL/MIN, 75 L/MIN | Actuation Type | Electrical, Manual |
| Seal Material | Fluorocarbon | Configuration | Normally Closed, Pressure Compensated |
| Power Consumption | 28 | Frequency | 100-400 |
| Operating Temperature | -15 to +400 | Current | 2.33 @ 12 VDC, 1.17 @ 24 VDC |
| Coil Nut Tightening Torque | 3 | Body Material | n/a |
| Flow Rate Accuracy | N/A | Minimum Pressure Differential | 200 |
| For Fluid Type | Mineral-based or synthetic hydraulic fluids | Operation Type | Solenoid operated, Manually opertated |
| Seal Material | Fluorocarbon | Maximum Regulated Flow Rate | 56.8 |
| Flow Direction | Inlet port 3, Bypass port 2, Regulated port 4 | Configuration | Normally Closed, Pressure Compensated |
| Actuation Type | Electrical, Manual | Maximum Inlet Pressure Rating | 3000 |
| Valve Material | All parts steel. All operating parts hardened steel | Hysteresis | < 15% |
| Maximum Kinematic Viscosity | 45-2000 SSU (6 to 420 cSt) | Filter Efficiency Rating | ISO 4406 18/16/13, SAE Class 4 |
| Function | Proportional Flow Control/Regulator | Connection Type | n/a |
| Installation Torque | 55 | Maximum Operating Pressure | 3000 |
| Weight | 1 | Minimum Operating Temperature | -15 |
| Leak Rate | 568 @ 3000 PSI (210 BAR) | Coil Type | 5/8" Super Coil High Watt (CAP) |
| Override Functionality | Infinite Control | Maximum Operating Temperature | +400 |
| Variation of Opening Point | N/A | Flow Rate | 20 |
| Connection Size | n/a | Division | Hydraulic Systems Division |
| Maximum Flow Rate | 20 | Cavity Size | C12-4L |
