| Port Type | NPT | Body Material | Stainless Steel |
| Media | General Purpose | Function | Normally Closed |
| Input Voltage | 24.0 | Specifications Met | N/A |
| Valve Configuration | 2 Way | Ingress Protection Rating | N/A |
| Maximum Ambient Temperature | 77.0 | Minimum Pressure Differential | 0.0 |
| Insulation Class | Class H | Coil Type | L322C2 |
| Seal Material | NYLON | Port Size | 1/8 |
| Installation | IOM 7206 | Orifice Size | 1/32 |
| Actuation Type | Direct Acting | Power Consumption | 22.0 |
| Main Flow Coefficient | 0.021 | Maximum Fluid Temperature | 185.0 |
| Preventive Maintenance Kit | N/A | Maximum Pressure Differential | 3000.0 |
| Port Type | NPT | Body Material | Stainless Steel |
| Division | Fluid Control Division | Specifications Met | N/A |
| Input Voltage | 24.0 VDC | Actuation Type | Direct Acting |
| Media | General Purpose | Function | Normally Closed |
| Minimum Pressure Differential | 0.0 psi | Valve Configuration | 2 Way |
| Ingress Protection Rating | N/A | Maximum Ambient Temperature | 77.0 °F |
| Insulation Class | Class H | Port Size | 1/8 inch |
| Preventive Maintenance Kit | n/a | Orifice Size | 1/32 inch |
| Coil Type | L322C2 | Seal Material | NYLON |
| Power Consumption | 22.0 W | Maximum Fluid Temperature | 185.0 °F |
| Maximum Pressure Differential | 3000.0 psi | Installation | IOM 7206 |
| Main Flow Coefficient | 0.021 Cv | | |
