Air Brake DOT Single & Double Check Valves - VS369PTCRCKP-4-4

Name: Air Brake DOT Single & Double Check Valves - VS369PTCRCKP-4-4
SKU: VS369PTCRCKP-4-4

Parker's DOT Check Valves were designed to deliever increased flow capacity and reliable sealing.

Availability:

Backordered

SKU VS369PTCRCKP-4-4

POR

Qty:

Products specifications

Attribute name	Attribute value
Connection 1 Type	Male NPT Thread	Connection 1 Size	1/4 inch
Valve Type	Single Check Valve	Connection 3 Size	N/A
Connection 2 Type	Push-to-Connect	Body Material	Composite
Shape	90° Elbow	Product Style	Tube to Pipe
Connection 3 Type	N/A	Connection 2 Size	1/4 inch
Product Type	Check Valves	Division	Fluid System Connectors Division
Tube Material	J844 Type A & B Nylon Tubing	Connection 1 Size	1/4
Collet Material	Brass	Industry	Automotive, Trucks, and Buses
Product Style	Tube to Pipe	Connection 3 Type	N/A
Connection 2 Type	Push-to-Connect	Specifications Met	SAE J1409 & SAE J1410
Thread Sealant Material	Vibra-Seal	Valve Type	Single Check Valve
O-Ring Material	Buna N	Body Material	Composite
Media	Compressed Air	Division	Fluid System Connectors Division
Connection 2 Size	1/4	Brand	PARKER
Connection 1 Type	Male NPT Thread	Application	Air Brake
Technology	Fluid & Gas Handling	Shape	90° Elbow
Connection 3 Size	N/A
