| Seal Material | Fluorocarbon | Configuration | Normally Closed |
| Maximum Inlet Pressure Rating | 5000 PSI, 350 BAR | Flow Rate | 4, 4.5 GAL/MIN, 15, 17 L/MIN |
| Override Functionality | Non-Detented | Seal Material | Fluorocarbon |
| Body Material | n/a | Maximum Operating Pressure | 5000 psi |
| Division | Hydraulic Systems Division | Maximum Kinematic Viscosity | 45-2000 SSU (6 to 420 cSt) |
| Minimum Operating Temperature | -26 °C | Weight | 0.15 kg |
| Maximum Inlet Pressure Rating | 350 bar | Installation Torque | 30 Nm |
| Coil Nut Tightening Torque | 3 lb-ft | Cavity Size | C08-4 |
| Configuration | Normally Closed | Actuation Type | Electrical, Manual |
| Maximum Operating Temperature | +204 °C | Filter Efficiency Rating | ISO 4406 18/16/13, SAE Class 4 |
| Frequency | 100-400 Hz | For Fluid Type | Mineral-based or synthetic hydraulic fluids |
| Operation Type | Solenoid operated, Manually operated | Valve Material | All parts steel. All operating parts hardened steel |
| Operating Temperature | -26 to +204 °C | Coil Type | 1/2" Super Coil |
| Response Time | 50 ms | Maximum Tank Pressure | 3000 psi |
| Function | Proportional Directional Control | Leak Rate | 10 @ 3000 PSI (210 BAR) cm3/min |
| Hysteresis | Less than 6% | Flow Rate Accuracy | +/- 15% @ 75% Nominal Current and Constant DeltaP Maintained with Pressure Compensator |
| Variation of Opening Point | 25% - 30% of Input Signal | Current | 1.15 @ 12 VDC, 1.58 @ 12 VDC, 0.58 @ 24 VDC, 0.79 @ 24 VDC A |
| Flow Rate | 4, 4.5 Gal/min | Maximum Flow Rate | 4, 4.5 Gal/min |
| Power Consumption | 14, 19 W | Override Functionality | Non-Detented |
