Fuel Filter Water Separator – Racor Spin-on Series - 215R10MTC

Name: Fuel Filter Water Separator – Racor Spin-on Series - 215R10MTC
SKU: 215R10MTC

Racor Spin-on Series Fuel Filter Water Separators provide maximum protection of modern engines by effectively removing water, sand, dirt, and rust contamination from fuel. Integral priming pump and fuel heater available as an option.

Availability:

Backordered

SKU 215R10MTC

POR

Qty:

Products specifications

Attribute name	Attribute value
Micron Rating	98% @ 10 Micron	Mounting	Bracket Included
Bowl Type	Standard, Clear Engineering Plastic	Flow Rate	15 gph (57 lph)
Part Type	Filter Assembly	Bowl Material	Clear Engineering Plastic
Heater Power Rating	No Heater	Location	EMEA region only
Port Size	M14 1.5 SAE	Product Series	Diesel Spin-on 200
Integral Primer Pump Included	Hand Plunger Priming Pump (Diesel or Gasoline)	Division	Engine Mobile Original Equipment Division
Brand	Racor	Operating Temperature	-40 to 121 °C
Product Type	Diesel Spin-on FF/WS	Head Material	Aluminium Alloy
For Fluid Type	Diesel and Gasoline	Filter Element Type	10 Micron Aquabloc Spin-on
Accessories Included	See Product Support Tab	Weight	1.8 lb / 0.80 Kg
Maximum Operating Pressure	207.0 kPa	Depth	4 inch
Width	102.0 mm	Height	211.0 mm
Number of Ports	1 Inlet / 2 Outlet	Compatible Element	R15S = "2" Micron<br/>R15T = 10 Micron<br/>R15P = 30 Micron
Clean Pressure Drop	0.83 kPa	Maximum Fluid Temperature	88.0 °C
