Fuel Filter Water Separator – Racor Spin-on Series - 230R2

Name: Fuel Filter Water Separator – Racor Spin-on Series - 230R2
SKU: 230R2

Racor Spin-on Series Fuel Filter Water Separators provide maximum protection of modern engines by effectively removing water, sand, dirt, and rust contamination from fuel. Integral priming pump and fuel heater available as an option.

Availability:

Backordered

SKU 230R2

POR

Qty:

Products specifications

Attribute name	Attribute value
Location	North America and EMEA regions	Micron Rating	98% @ 4 Micron
Mounting	Bracket Included	Bowl Type	Standard, Clear Engineering Plastic
Part Type	Filter Assembly	Port Size	1/4" NPTF
Bowl Material	Clear Engineering Plastic	Heater Power Rating	No Heater
Product Series	Diesel Spin-on 200	Integral Primer Pump Included	Hand Plunger Priming Pump (Diesel or Gasoline)
Flow Rate	30 gph (114 lph)	Division	Engine Mobile Original Equipment Division
Brand	Racor	Operating Temperature	-40 to 121 °C
Product Type	Diesel Spin-on FF/WS	Head Material	Aluminium Alloy
For Fluid Type	Diesel and Gasoline	Filter Element Type	2 Micron Aquabloc Spin-on
Accessories Included	See Product Support Tab	Maximum Operating Pressure	207.0 kPa
Depth	4 inch	Width	102.0 mm
Number of Ports	1 Inlet / 2 Outlet	Maximum Fluid Temperature	190.0 °F
Height	229.0 mm	Weight	2 lb / 0.90 Kg
Compatible Element	R20S = "2" Micron<br/>R20T = 10 Micron<br/>R20P = 30 Micron	Clean Pressure Drop	0.31 psi

Product resources

Distributor Support, Literature and Reference Materials, Selector Guides

Racor--200 Diesel Spin-on--RSL0376 (PDF)

Literature and Reference Materials
