Fuel Filter Water Separator – Racor Spin-on Series - 345RC122

Name: Fuel Filter Water Separator – Racor Spin-on Series - 345RC122
SKU: 345RC122

Racor Spin-on Series Fuel Filter Water Separators provide maximum protection of modern engines by effectively removing water, sand, dirt, and rust contamination from fuel. Integral priming pump and fuel heater available as an option.

Availability:

Backordered

SKU 345RC122

POR

Qty:

Products specifications

Attribute name	Attribute value
Location	North America and EMEA regions	Micron Rating	98% @ 4 Micron
Mounting	Bracket Included	Bowl Type	Standard, Clear Engineering Plastic
Part Type	Filter Assembly	Bowl Material	Clear Engineering Plastic
Integral Primer Pump Included	No Pump	Flow Rate	45 gph (170 lph)
Product Series	Diesel Spin-on 300	Port Size	3/8"-18 NPTF (SAE J476)
Heater Power Rating	12V / 200W Heater with Coolant Heat Exchanger (Diesel Only)	Division	Engine Mobile Original Equipment Division
Brand	Racor	Operating Temperature	-40 to 250 °F
Product Type	Diesel Spin-on FF/WS	Head Material	Aluminium Alloy
Filter Element Type	2 Micron Aquabloc Spin-on	Accessories Included	See Product Support Tab
Maximum Operating Pressure	207.0 kPa	For Fluid Type	Diesel
Maximum Fluid Temperature	88.0 °C	Depth	112.0 mm
Width	4.8 inch	Height	9.3 inch
Weight	2.5 lb / 1.1 Kg	Number of Ports	2 Fuel / 2 Coolant
Compatible Element	R45S = "2" Micron<br/>R45T = 10 Micron<br/>R45P = 30 Micron	Clean Pressure Drop	0.69 kPa
