Fuel Filter Water Separator – Racor Spin-on Series - 445R2

Name: Fuel Filter Water Separator – Racor Spin-on Series - 445R2
SKU: 445R2

Racor Spin-on Series Fuel Filter Water Separators provide maximum protection of modern engines by effectively removing water, sand, dirt, and rust contamination from fuel. Integral priming pump and fuel heater available as an option.

Availability:

Backordered

SKU 445R2

POR

Qty:

Products specifications

Attribute name	Attribute value
Location	North America and EMEA regions	Micron Rating	98% @ 4 Micron
Mounting	Bracket Included	Bowl Type	Standard, Clear Engineering Plastic
Part Type	Filter Assembly	Bowl Material	Clear Engineering Plastic
Heater Power Rating	No Heater	Flow Rate	45 gph (170 lph)
Port Size	3/8"-18 NPTF (SAE J476)	Product Series	Diesel Spin-on 400
Integral Primer Pump Included	Button Priming Pump (Diesel)	Division	Engine Mobile Original Equipment Division
Brand	Racor	Operating Temperature	-40 to 250 °F
Product Type	Diesel Spin-on FF/WS	Head Material	Aluminium Alloy
Number of Ports	2 Inlet / 2 Outlet	Filter Element Type	2 Micron Aquabloc Spin-on
Accessories Included	See Product Support Tab	Maximum Operating Pressure	30 psi
For Fluid Type	Diesel	Maximum Fluid Temperature	88.0 °C
Height	9.3 inch	Compatible Element	R45S = "2" Micron<br/>R45T = 10 Micron<br/>R45P = 30 Micron
Width	114.0 mm	Depth	121.0 mm
Weight	2.5 lb	Clean Pressure Drop	0.17 psi

Product resources

Literature and Reference Materials, Selector Guides

Racor--400 Diesel Spin-on--RSL0366 (PDF)

Literature and Reference Materials
