Fuel Filter Water Separator – Racor Spin-on Series - 490RHH10MTC

Name: Fuel Filter Water Separator – Racor Spin-on Series - 490RHH10MTC
SKU: 490RHH10MTC

Racor Spin-on Series Fuel Filter Water Separators provide maximum protection of modern engines by effectively removing water, sand, dirt, and rust contamination from fuel. Integral priming pump and fuel heater available as an option.

Availability:

Backordered

SKU 490RHH10MTC

POR

Qty:

Products specifications

Attribute name	Attribute value
Micron Rating	98% @ 10 Micron	Mounting	Bracket Included
Part Type	Filter Assembly	Bowl Material	Clear Engineering Plastic
Location	EMEA region only	Bowl Type	Deep Bowl, Clear Engineering Plastic
Product Series	Diesel Spin-on 400	Port Size	M16 1.5 SAE
Integral Primer Pump Included	Button Priming Pump (Diesel)	Heater Power Rating	In Head PTC Heater (12V to 24V) (Diesel Only)
Flow Rate	90 gph (341 lph)	Division	Engine Mobile Original Equipment Division
Brand	Racor	Operating Temperature	-40 to 121 °C
Product Type	Diesel Spin-on FF/WS	Head Material	Aluminium Alloy
Number of Ports	2 Inlet / 2 Outlet	Filter Element Type	10 Micron Aquabloc Spin-on
Accessories Included	See Product Support Tab	Maximum Operating Pressure	207.0 kPa
For Fluid Type	Diesel	Maximum Fluid Temperature	190.0 °F
Depth	4.7 inch	Width	4.4 inch
Weight	4.2 lb	Height	289.0 mm
Compatible Element	R90SL-D-MAX = "2" Micron<br/>R90T-D-MAX = 10 Micron<br/>R90P-D-MAX = 30 Micron	Clean Pressure Drop	0.95 psi
