Fuel Filter Water Separator – Racor Spin-on Series - 660R2MTC

Name: Fuel Filter Water Separator – Racor Spin-on Series - 660R2MTC
SKU: 660R2MTC

Racor Spin-on Series Fuel Filter Water Separators provide maximum protection of modern engines by effectively removing water, sand, dirt, and rust contamination from fuel. Integral priming pump and fuel heater available as an option.

Availability:

Backordered

SKU 660R2MTC

POR

Qty:

Products specifications

Attribute name	Attribute value
Micron Rating	98% @ 4 Micron	Mounting	Bracket Included
Bowl Type	Standard, Clear Engineering Plastic	Part Type	Filter Assembly
Bowl Material	Clear Engineering Plastic	Heater Power Rating	No Heater
Integral Primer Pump Included	No Pump	Location	EMEA region only
Flow Rate	60 gph (227 lph)	Port Size	M16 1.5 SAE
Product Series	Diesel Spin-on 600	Division	Engine Mobile Original Equipment Division
Brand	Racor	Maximum Operating Pressure	30
Product Type	Diesel Spin-on FF/WS	Head Material	Aluminium Alloy
For Fluid Type	Diesel and Gasoline	Number of Ports	2 Inlet / 2 Outlet
Filter Element Type	2 Micron Aquabloc Spin-on	Accessories Included	See Product Support Tab
Operating Temperature	-40 to 250	Maximum Fluid Temperature	190.0
Width	4.5	Compatible Element	R60S = "2" Micron<br/>R60T = 10 Micron<br/>R60P = 30 Micron
Weight	2.6	Depth	4.5
Height	10.2	Clean Pressure Drop	0.05
