Picture of Fuel Filter Water Separator – Racor Spin-on Series - 690R10

*PRODUCT IMAGE IS REPRESENTATIVE PROVIDED BY THE MANUFACTURER. DO NOT MAKE BUYING DECISIONS SOLEY BASED ON THE IMAGE. PLEASE VERIFY SPECIFICATIONS MEET YOUR REQUIREMENTS.

Fuel Filter Water Separator – Racor Spin-on Series - 690R10

Racor Spin-on Series Fuel Filter Water Separators provide maximum protection of modern engines by effectively removing water, sand, dirt, and rust contamination from fuel. Integral priming pump and fuel heater available as an option.
Availability:
Backordered
SKU 690R10
POR
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options
Products specifications
Attribute nameAttribute value
Part TypeFilter AssemblyLocationNorth America and EMEA regions
Integral Primer Pump IncludedNo PumpMountingBracket Included
Flow Rate90 gph (341 lph)Bowl MaterialClear Engineering Plastic
Heater Power RatingNo HeaterProduct SeriesDiesel Spin-on 600
Bowl TypeStandard, Clear Engineering PlasticPort Size3/8"-18 NPTF (SAE J476)
Micron Rating98% @ 10 MicronFilter Element Type10 Micron Aquabloc Spin-on
BrandRacorHead MaterialAluminium Alloy
Compatible ElementR90S = "2" Micron<br/>R90T = 10 Micron<br/>R90P = 30 MicronDepth114.0 mm
Number of Ports2 Inlet / 2 OutletAccessories IncludedSee Product Support Tab
Maximum Operating Pressure207.0 kPaDivisionEngine Mobile Original Equipment Division
Maximum Fluid Temperature190.0 °FWeight1.2 kg
Clean Pressure Drop2 kPaProduct TypeDiesel Spin-on FF/WS
Width4.5 inchFor Fluid TypeDiesel and Gasoline
Operating Temperature-40 to 250 °FHeight11.2 inch
