Fuel Filter Water Separator with Integrated Priming Pump – Racor 700 Series - 790R3024

Name: Fuel Filter Water Separator with Integrated Priming Pump – Racor 700 Series - 790R3024
SKU: 790R3024

The Racor 700 Series Fuel Filter Water Separator is a two-stage filtration system designed for use in diesel engine applications. Its integrated fuel pump allows for easy system priming and eliminates messy filter pre-filling and engine hard starting.

Availability:

Backordered

SKU 790R3024

POR

Qty:

Products specifications

Attribute name	Attribute value
Micron Rating	98% @ 30 microns	Flow Rate	90 gph / 340 lph
Pump Type	12/24V DC Brushless	Division	Engine Mobile Original Equipment Division
Brand	Racor	Bowl Type	Clear Engineering Plastic
For Fluid Type	Diesel	Application	Electric Priming
Product Series	Cartridge FF/WS Pump	Depth	6.5
Width	4.3	Port Size	7/8"-14
Mounting Type	Head Bracket	Clean Pressure Drop	0.25
Water Sensor Option	Included	Optional Accessories	See Product Overview & Support Tabs
Height	12.8	Pump Type	63 gph (240 lph)
Compatible Element	R90P

Product resources

Literature and Reference Materials
