HONEYCOMB™ HFT Wound Depth Liquid Filter Cartridge - 100913

Name: HONEYCOMB™ HFT Wound Depth Liquid Filter Cartridge - 100913
SKU: 100913

Honeycomb™ wound depth filter cartridges remove contaminants from a wide range of liquid applications. Parker strings are known for superior quality and performance. Available from 0.5 to 150 micron ratings with a variety of string materials.

Availability:

Backordered

SKU 100913

POR

Qty:

Products specifications

Attribute name	Attribute value
Core Material	Tin-Plated Steel	Micron Rating	75
End Cap Material	N/A	End Cap Configuration	DOE - Double Open End
Industry	Oil & Gas and Industrial	Packaging	Standard
Seal Material	N/A	Filter Material	Cotton (FDA)
Core Cover Material	Non Woven Polyester	Nominal Outside Diameter	2.4375"
Maximum Operating Temperature	250 F	Model Number	ELMT 10R8V
Cartridge Length	8"	Division	Industrial Process Filtration Division
Brand	PARKER	Division	Industrial Process Filtration Division
Technology	Filtration	Application	Liquid Particulate Filtration
Product Type	Filter Cartridge	Flow Direction	Outside-to-inside
Product Series	HFT	Quantity per Box	30
Filter Construction	Wound String	Nominal Inside Diameter	1"
Maximum Pressure Differential	60 PSID	Changeout Pressure Differential	30 PSID

Product resources

Literature and Reference Materials

HONEYCOMB™ HFT Wound Depth Liquid Filter Cartridge (PDF)
