Picture of Low Pressure Spin-On Filters 12AT/50AT Series - 12AT120BBPGS12N

*PRODUCT IMAGE IS REPRESENTATIVE PROVIDED BY THE MANUFACTURER. DO NOT MAKE BUYING DECISIONS SOLEY BASED ON THE IMAGE. PLEASE VERIFY SPECIFICATIONS MEET YOUR REQUIREMENTS.

Low Pressure Spin-On Filters 12AT/50AT Series - 12AT120BBPGS12N

Our rebranded Spin-On Low Pressure Filter Series are cost effective yet uncompromising in performance and quality. Max allowable operating pressure of 150 PSI/10.3 Bar and capable of flows up to 50 GPM/190 LPM depending on viscosity.
Availability:
Backordered
SKU 12AT120BBPGS12N
POR
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options
Products specifications
Attribute nameAttribute value
Seal MaterialNitrileOptionsNone
Flow Rate (gpm)13Indicator TypeSold separately
Bypass Valve (psi)25Port Connection TypeSAE-12 ports
Filter Element20 micron microglassMounting TypeInline
Seal MaterialNitrileDivisionEngine Mobile Hydraulic and Fuel Filtration Division
OptionsNoneMaximum Operating Temperature107
Weight1.6For Fluid TypeSuitable for use with mineral and vegetable oils, and some synthetic oils. For other fluids, please e-mail Technical Support at HFF.technical@support.parker.com or call 800-253-1258.
Flow Rate13Port TypeSAE-12 ports
Indicator TypeSold separatelyPressure Rating150
Housing MaterialLow Carbon SteelIndicator Pressure Setting1.4
Bypass Valve Pressure Rating25Compatible Element928764
Filter Element Type20 micron microglass
