Low Pressure Spin-On Filters 12AT/50AT Series - 80AT2WRBPGY32H

Name: Low Pressure Spin-On Filters 12AT/50AT Series - 80AT2WRBPGY32H
SKU: 80AT2WRBPGY32H

Our rebranded Spin-On Low Pressure Filter Series are cost effective yet uncompromising in performance and quality. Max allowable operating pressure of 150 PSI/10.3 Bar and capable of flows up to 50 GPM/190 LPM depending on viscosity.

Availability:

Backordered

SKU 80AT2WRBPGY32H

POR

Qty:

Products specifications

Attribute name	Attribute value
Filter Element	10 micron Pargel	Port Connection Type	2" SAE Code 61 Flange / 1-1/2" NPT ports
Seal Material	Nitrile	Flow Rate (gpm)	80
Indicator Type	Sold separately	Options	Inlet & Outlet, both sides (all ports drilled & tapped)
Bypass Valve (psi)	25 psid bypass	Filter Element Type	10 micron Pargel
Options	Inlet & Outlet, both sides (all ports drilled & tapped)	Pressure Rating	150
Mounting Type	Inline	Bypass Valve Pressure Rating	25
Port Type	2" SAE Code 61 Flange / 1-1/2" NPT ports	Division	Engine Mobile Hydraulic and Fuel Filtration Division
Indicator Pressure Setting	20	Seal Material	Nitrile
Flow Rate	302	Weight	13
Compatible Element	FA511-10W	For Fluid Type	Suitable for use with mineral and vegetable oils, and some synthetic oils. For other fluids, please e-mail Technical Support at HFF.technical@support.parker.com or call 800-253-1258.
Maximum Operating Temperature	225	Indicator Type	Sold separately
Housing Material	Low Carbon Steel

Product resources

Literature and Reference Materials
