Picture of Marine Fuel Filter Water Separator – Racor Spin-on Series - 230RMAM

*PRODUCT IMAGE IS REPRESENTATIVE PROVIDED BY THE MANUFACTURER. DO NOT MAKE BUYING DECISIONS SOLEY BASED ON THE IMAGE. PLEASE VERIFY SPECIFICATIONS MEET YOUR REQUIREMENTS.

Marine Fuel Filter Water Separator – Racor Spin-on Series - 230RMAM

Racor Marine Spin-on Series Fuel Filter Water Separators provide maximum protection of modern engines by effectively removing water, sand, dirt, and rust contamination from fuel. UL-approved versions available.
Availability:
Backordered
SKU 230RMAM
POR
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options
Products specifications
Attribute nameAttribute value
Micron Rating98% @ 10 MicronFlow Rate30 gph / 114 lph
Port Size1/4”-18 NPTFBowl MaterialAluminum Bowl
Filtered MediumDieselUL CertificationYes
Integral Primer PumpYesDivisionEngine Mobile Original Equipment Division
BrandRacorOperating Temperature-40 to 121 °C
Head MaterialPower Coated Aluminium AlloyFilter Element Type10 Micron Aquabloc Spin-on
Mounting TypeBracket IncludedDepth4 inch
Number of Ports1 Inlet / 2 OutletMaximum Fluid Temperature88.0 °C
Maximum Operating Pressure206.8 kPaWidth3.9 inch
Height22.9 cmWeight2.0 lb / 0.5 Kg
Compatible ElementR20S = 2 micron<br/>R20TUL = 10 micron<br/>R20PUL = 30 micronClean Pressure Drop2.07 kPa
Product SeriesDiesel Spin-on
Product resources

Compliance, Certifications & Safety, Literature and Reference Materials

Distributor Support, Literature and Reference Materials, Selector Guides

Literature and Reference Materials
