Picture of Marine Fuel Filter Water Separator – Racor Spin-on Series - 245RMAM

*PRODUCT IMAGE IS REPRESENTATIVE PROVIDED BY THE MANUFACTURER. DO NOT MAKE BUYING DECISIONS SOLEY BASED ON THE IMAGE. PLEASE VERIFY SPECIFICATIONS MEET YOUR REQUIREMENTS.

Marine Fuel Filter Water Separator – Racor Spin-on Series - 245RMAM

Racor Marine Spin-on Series Fuel Filter Water Separators provide maximum protection of modern engines by effectively removing water, sand, dirt, and rust contamination from fuel. UL-approved versions available.
Availability:
Backordered
SKU 245RMAM
POR
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options
Products specifications
Attribute nameAttribute value
Micron Rating98% @ 10 MicronPort Size1/4”-18 NPTF
Bowl MaterialAluminum BowlFiltered MediumDiesel
UL CertificationYesIntegral Primer PumpYes
Flow Rate45 gph / 170 lphDivisionEngine Mobile Original Equipment Division
BrandRacorMaximum Operating Pressure30
Head MaterialPower Coated Aluminium AlloyFilter Element Type10 Micron Aquabloc Spin-on
Operating Temperature-40 to 250Maximum Fluid Temperature190.0
Mounting TypeBracket IncludedProduct SeriesMarine Spin-on FF/WS
Depth4Width4
Number of Ports1 Inlet / 2 OutletHeight26.7
Weight2.2 lb / 1.0 KgCompatible ElementR25TUL = 10 micron<br/>R25P = 30 micron<br/>R25S = 2 micron
Clean Pressure Drop0.6
Product resources

Compliance, Certifications & Safety, Literature and Reference Materials

Distributor Support, Literature and Reference Materials, Selector Guides

Literature and Reference Materials
