Marine Fuel Filter Water Separator – Racor Spin-on Series - 4120MAM30

Name: Marine Fuel Filter Water Separator – Racor Spin-on Series - 4120MAM30
SKU: 4120MAM30

Racor Marine Spin-on Series Fuel Filter Water Separators provide maximum protection of modern engines by effectively removing water, sand, dirt, and rust contamination from fuel. UL-approved versions available.

Availability:

Backordered

SKU 4120MAM30

POR

Qty:

Products specifications

Attribute name	Attribute value
Micron Rating	98% @ 30 Micron	Bowl Material	Aluminum Bowl
Filtered Medium	Diesel	UL Certification	Yes
Integral Primer Pump	Yes	Flow Rate	120 gph / 454 lph
Port Size	3/4" SAE	Division	Engine Mobile Original Equipment Division
Brand	Racor	Clean Pressure Drop	0.5 psi
Operating Temperature	-40 to 121 °C	Head Material	Power Coated Aluminium Alloy
Number of Ports	2 Inlet / 2 Outlet	Filter Element Type	30 Micron Aquabloc Spin-on
Mounting Type	Bracket Included	Maximum Fluid Temperature	190.0 °F
Product Series	Diesel Spin-on	Weight	3.3 lb / 1.5 Kg
Compatible Element	S3201PUL = 30 micornS3201TUL = 10 micron<br/>S3201S = 2 micron	Maximum Operating Pressure	15 psi
Width	4.5 inch	Depth	12.2 cm
Height	32.5 cm
