Marine Fuel Filter Water Separator – Racor Spin-on Series - 445MAM10

Name: Marine Fuel Filter Water Separator – Racor Spin-on Series - 445MAM10
SKU: 445MAM10

Racor Marine Spin-on Series Fuel Filter Water Separators provide maximum protection of modern engines by effectively removing water, sand, dirt, and rust contamination from fuel. UL-approved versions available.

Availability:

Backordered

SKU 445MAM10

POR

Qty:

Products specifications

Attribute name	Attribute value
Micron Rating	98% @ 10 Micron	Bowl Material	Aluminum Bowl
Filtered Medium	Diesel	UL Certification	Yes
Integral Primer Pump	Yes	Flow Rate	45 gph / 170 lph
Port Size	3/8"-18 NPTF	Division	Engine Mobile Original Equipment Division
Brand	Racor	Operating Temperature	-40 to 121 °C
Head Material	Power Coated Aluminium Alloy	Number of Ports	2 Inlet / 2 Outlet
Filter Element Type	10 Micron Aquabloc Spin-on	Mounting Type	Bracket Included
Maximum Fluid Temperature	88.0 °C	Product Series	Diesel Spin-on
Clean Pressure Drop	1.38 kPa	Depth	12.2 cm
Compatible Element	S3204TUL = 10 micron<br/>S3204P = 30 micron<br/>S3204S = 2 micron	Width	11.4 cm
Height	9.4 inch	Weight	1.3 kg
Maximum Operating Pressure	103.4 kPa

Product resources

Compliance, Certifications & Safety, Literature and Reference Materials

Racor EB00033 Marine Gasoline Spin-on Filters - Bowl Inspection (PDF)

Distributor Support, Literature and Reference Materials, Selector Guides

Literature and Reference Materials
