Picture of Parker 3-Way Normally Open, 1/4" NPT General Purpose Solenoid Valves - 04F30O2108ACFPH01

*PRODUCT IMAGE IS REPRESENTATIVE PROVIDED BY THE MANUFACTURER. DO NOT MAKE BUYING DECISIONS SOLEY BASED ON THE IMAGE. PLEASE VERIFY SPECIFICATIONS MEET YOUR REQUIREMENTS.

Parker 3-Way Normally Open, 1/4" NPT General Purpose Solenoid Valves - 04F30O2108ACFPH01

Parker 3-Way Normally Open, 1/4" NPT Solenoid Valves provide operating pressures up to 235 psi (AC) and flow factors up to 0.25 CV's. They offer a brass body, multiple mounting positions and coil options for all general purpose flow control applications.
Availability:
Backordered
SKU 04F30O2108ACFPH01
POR
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options
Products specifications
Attribute nameAttribute value
Coil TypeDIN Form A, Class FVoltage (V)24/60
Power (Watts)11 Watt (AC)Maximum Pressure Differential (psi)70 psi (AC)
Orifice Main (inch)1/8Flow Factor Main (Cv)0.25
Port Size1/4Port TypeNPT
DivisionFluid Control DivisionMediaGeneral Purpose for Air
FunctionNormally Open (NO)Coil TypeDIN Form A, Class F
Valve Type3-WayBody MaterialBrass
Input Voltage24/60Seal MaterialNBR
Actuation TypeDirect ActingOrifice 2 Sizen/a
Product SeriesGold Ring SeriesNumber of Ports3
Power Consumption11 W (AC)Flow Coefficient 2n/a
Coil Specifications MetClass FMaximum Fluid Temperature200
Minimum Fluid Temperature0Maximum Pressure Differential70 psi (AC)
Minimum Pressure Differential0Main Orifice Size1/8
Additional Optionsn/aExhaust Orifice Size1/8
Main Flow Coefficient0.25Exhaust Flow Coefficient0.25
