Picture of Pneumatic Cylinders, Industrial Grade – Series MA/Series MAN - SERIES MA AND SERIES MAN

*PRODUCT IMAGE IS REPRESENTATIVE PROVIDED BY THE MANUFACTURER. DO NOT MAKE BUYING DECISIONS SOLEY BASED ON THE IMAGE. PLEASE VERIFY SPECIFICATIONS MEET YOUR REQUIREMENTS.

Pneumatic Cylinders, Industrial Grade – Series MA/Series MAN - SERIES MA AND SERIES MAN

Series MA and MAN industrial grade pneumatic cylinders have a no-compromise design and proven reliability and are the high performing, longer-lasting choice for your air cylinder applications.
Availability:
Backordered
SKU SERIES MA AND SERIES MAN
POR
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options
Products specifications
Attribute nameAttribute value
Rod Diameter0.625 to 1.375TechnologyPneumatics
Mounting Type11 Standard StylesProduct TypeCylinder Actuator
Operating Pressure200Bore Diameter1 to 6
Product SeriesSeries MA, MAN Industrial Grade Pneumatic CylindersSpecifications MetANSI (NFPA) T3.6.7R3-2009
DivisionCylinder DivisionMaterials of ConstructionSteel
Operating Temperature-10 to 165ConfigurationTie Rod
For Fluid TypeFiltered AirStroke LengthAvailable in any practical stroke length.
Product resources

Compliance, Certifications & Safety

Literature and Reference Materials
