| Seal Material | Nitrile | Override Functionality | N/A |
| Maximum Inlet Pressure Rating | 5000 PSI, 350 BAR | Configuration | Pressure Reducing/Relieving |
| Maximum Flow Rate | 10 GAL/MIN, 37.5 L/MIN | Wire Mesh Screen Included | N/A |
| Maximum Regulating Pressure | 300 PSI, 21 BAR | Actuation Type | Electrical |
| Seal Material | Nitrile | Body Material | n/a |
| Maximum Operating Pressure | 5000 psi | Division | Hydraulic Cartridge Systems Division |
| Division | Hydraulic Systems Division | Maximum Kinematic Viscosity | 45-2000 SSU (6 to 420 cSt) |
| Minimum Operating Temperature | -34 °C | Cavity Size | C10-3L |
| Override Functionality | n/a | Wire Mesh Screen Included | n/a |
| Maximum Inlet Pressure Rating | 350 bar | Operation Type | Solenoid Operated |
| Maximum Flow Rate | 10 Gal/min | Configuration | Pressure Reducing/Relieving |
| Maximum Operating Temperature | +121 °C | Filter Efficiency Rating | ISO 4406 18/16/13, SAE Class 4 |
| Hysteresis | 4% | For Fluid Type | Mineral-based or synthetic hydraulic fluids |
| Valve Material | All parts steel. All operating parts hardened steel | Operating Temperature | -34 to +121 °C |
| Mounting Type | Screw in cartridge valve | Weight | 0.59 kg |
| Coil Type | 1/2" Super Coil Low Watt (CCS) | Installation Torque | 37-41 lb-ft |
| Maximum Tank Pressure | N/A psi | Current | 0.9 at 12VDC, 0.45 at 24VDC A |
| Function | Proportional Pressure Reducing | Flow Rate | 37.5 L/min |
| Frequency | 200-600 Hz | Leak Rate | 492 @ 300 PSI (21 BAR), 946 @ 3000 PSI (210 BAR) cm3/min |
| Response Time | N/A ms | Flow Direction | Inlet port 1, Reducing port 2, Tank port 3 |
| Power Consumption | 9 @ Max Reduced Pressure W | Maximum Drain Flow Rate | N/A cm3/min |
| Maximum Pressure Setting | N/A psi | Coil Nut Tightening Torque | 7-9.5 Nm |
| Maximum Regulating Pressure | 21 bar | | |
