| Seal Material | Nitrile | Override Functionality | N/A |
| Maximum Inlet Pressure Rating | 3000 PSI, 210 BAR | Maximum Flow Rate | 8 GAL/MIN, 30 L/MIN |
| Wire Mesh Screen Included | Yes | Configuration | Side Cylinder Port |
| Maximum Regulating Pressure | 420-550 PSI, 29-38 BAR | Actuation Type | Electrical |
| Seal Material | Nitrile | Body Material | n/a |
| Division | Hydraulic Cartridge Systems Division | Division | Hydraulic Systems Division |
| Maximum Kinematic Viscosity | 45-2000 SSU (6 to 420 cSt) | Maximum Operating Pressure | 210 bar |
| Minimum Operating Temperature | -34 °C | Weight | 0.13 kg |
| Override Functionality | n/a | Maximum Flow Rate | 30 L/min |
| Flow Rate | 30 L/min | Wire Mesh Screen Included | Yes |
| Coil Type | 5/8" Super Coil High Watt (CAP) | Operation Type | Solenoid Operated |
| Power Consumption | 28 W | Installation Torque | 22 lb-ft |
| Coil Nut Tightening Torque | 4.1 Nm | Maximum Operating Temperature | +250 °F |
| Filter Efficiency Rating | ISO 4406 18/16/13, SAE Class 4 | Frequency | 100-400 Hz |
| For Fluid Type | Mineral-based or synthetic hydraulic fluids | Valve Material | All parts steel. All operating parts hardened steel |
| Operating Temperature | -34 to +121 °C | Maximum Inlet Pressure Rating | 210 bar |
| Mounting Type | Screw in cartridge valve | Response Time | 40 ms |
| Maximum Tank Pressure | N/A psi | Function | Proportional Pressure Reducing |
| Maximum Pressure Setting | N/A psi | Cavity Size | 3X |
| Leak Rate | N/A cm3/min | Current | 1.4 at 12VDC (High watt), 0.7 at 24VDC (High watt) A |
| Hysteresis | 3.5% | Configuration | Side Cylinder Port |
| Flow Direction | Inlet port 3, Reducing port 2, Tank port 1 | Maximum Drain Flow Rate | 25 De-Energized, 800 In Regulating Zone @ 300 PSI (21 BAR) cm3/min |
| Maximum Regulating Pressure | 420-550 psi | | |
