Picture of Silicone Greek Corrugated High Temperature Wire Reinforced Coolant Hose, Series 6621 - 6621-1000130

*PRODUCT IMAGE IS REPRESENTATIVE PROVIDED BY THE MANUFACTURER. DO NOT MAKE BUYING DECISIONS SOLEY BASED ON THE IMAGE. PLEASE VERIFY SPECIFICATIONS MEET YOUR REQUIREMENTS.

Silicone Greek Corrugated High Temperature Wire Reinforced Coolant Hose, Series 6621 - 6621-1000130

Silicone Greek Corrugated High Temperature Wire Reinforced Coolant Hose is for use in heater and radiator systems in heavy duty/high capacity vehicles and industrial equipment to 75 psi and 392°F, Series 6621
Availability:
Backordered
SKU 6621-1000130
POR
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options
Products specifications
Attribute nameAttribute value
Hose I.D. (inch)1Standard Pack Qty (ft)130
Minimum Burst Pressure (psi)225DivisionHose Products Division
MediaWaterPackage TypeCoil
Inside Diameter1 inchWeight0.14 kg
Cover ColorRedOutside Diameter35 mm
Minimum Bend Radius50 mmMaximum Operating Pressure75 psi
ApplicationSilicone CoolantSpecifications MetSAE J20R1, Class A
Vacuum Pressure Rating17.7 Inch-HgMaximum Operating Temperature200 °C
Minimum Operating Temperature-60 °CCover MaterialSilicone
Cover StructureGlossyHose Inner Tube MaterialSilicone
Hose Reinforcement MaterialMultiple Plies of High Temperature Textile with Wire HelixDesign Factor3:1
Minimum Burst Pressure225 psi
Product resources

Literature and Reference Materials
