Transair® Drop Brackets for Aluminum Pipe - RR63 L8N16

Name: Transair® Drop Brackets for Aluminum Pipe - RR63 L8N16
SKU: RR63 L8N16

Transair® Drop Brackets are designed for the quick and easy addition of drop lines to an existing compressed air pipe or inert gas system.

Availability:

Backordered

SKU RR63 L8N16

POR

Qty:

Products specifications

Attribute name	Attribute value
Connection 2 Size	2"	Connection 1 Size	6" (168 mm)
Connection 2 Type	Female Threaded NPT Saddle Reducing Bracket	Body Material	Cast Iron / Zinc-plated
Technology	Pneumatics	Maximum Operating Pressure	13 bar
Application	Inert Gases	Vacuum Pressure Rating	1.0 mbar
Product Type	Compressed Air Piping	Shape	Saddle
Connection 1 Size	168 mm	Configuration	Pipe to Port
Assembly Time	0.1 Hours	Weight	7.5 lb
Division	Low Pressure Connectors Europe Division	Minimum Operating Temperature	-20 °C
Assembly	Drop	For Fluid Type	Air
Plating Type	Zinc-plated	Body Material	Cast Iron
Industry	General Industrial	Product Style	Quick Assembly Bracket
Silicone Free	Yes	Brand	PARKER
Connection 1 Type	Pipe	Division	Low Pressure Connectors Europe Division
Maximum Operating Temperature	85 °C	Quantity per Box	1
Specifications Met	CE 2014/68/EU	Connection 2 Size	2 inch
Connection 2 Type	Female
